Specifications
gps gsm antenna magneticGPS:1575.42MHZ
GSM:850/900/1800/1900MHZ
ROHS Compliant
gps gsm magnetic antenna
Specification:
(i)Dielectric Antenna
Center Frequency(MHz):1575.42±3
VSWR:1.5:1
Bandwidth(MHz):±5
Impedance(Ω):50
Peak Gain >3dBi Based on 7cm×7cm ground plane
Gain Coverage >-4dBi at –90°<0 <+90°(over 75% Volume)
Polarization:RHCP
(ii)GSM Antenna
Center Frequency(MHz):850/900/1800/1900
Typical Gain:2dBi+/-1dBi@850MHz ; 2dBi+/-1dBi@900MHz
1dBi+/-1dBi@1800MHz;1dBi+/-1dBi@1900MHz
VSWR:2.0:1
Impedance(Ω):50
(iii)LNA/Filter
LNA Gain(Without Cable) :28 dBi Typical
Noise Figure(dB):1.5
Filter Out Band Attenuation (f0=1575.42 MHz)
7dB Min f0+/-20MHz ;
20dB Min f0+/-50MHz;
30dB Min f0+/-100MHz
VSWR <2.0
DC Voltage(V):2.7/3.0/3.3/5.0/3.0 to 5.0 etc.
DC Current(mA):11 Max
(iv)Mechanical
Weight(gram )<200
Size(mm):96×36×15
Cable GPS(m):RG174 2,5 etc.
GSM(m):RG174 2,5 etc.
Connector GPS:SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX etc.
GSM:SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX etc.
Mounting:Adhesive/Magnetic
Housing:Black
(v)Environmental
Working Temp:-40°C~+85°C
Storage Temp:-45°C~+100°C
Vibration:Sine sweep 1g(0-p)10~50~10Hz each axis
Humidity:Humidity95%~100%RH
Weatherproof:100%Waterproof
