Single / multimode rack-mount fiber optical splitter 1*4 plc
Applications
FTTX(FTTP,FTTH,FTTN,FTTC)
PassiveOpticalNetworks(PON)
LocalAreaNetworks(LAN)
CATV Systems
TestEquipments
Performance Specifications
Item |
Unit |
Parameter |
Operating Wavelength |
nm |
1260~1650 |
Typ.InsertionLoss |
dB |
7.0 |
Max.InsertionLoss |
dB |
7.3 |
Max.Uniformity |
dB |
0.6 |
Max.TDL |
dB |
0.5 |
Max.PDL |
dB |
0.2 |
Min.Return Loss |
dB |
50 |
Min.Directivity |
dB |
50 |
OperatingTemperature |
°C |
-40~+85 |
Storage Temperature |
°C |
-40~+85 |
Package Dimensions(L×W×H) |
mm |
40×4×4 |
Ordering information for Planar splitter (PLC splitter)
| Port | 12=1×2,14=1×4,18=1×8,116=1×16,132=1×32,164=1×64, 24=2×4,28=2×8,216=2×16,232=2×32 |
| Fiber Type | D=G652D, A=G 657A |
| Package | S=Steel tube; A=ABS box |
| Input Fiber Type | L=900µm Loose tube, S=2.0mm, R=3.0mm, B=250µm Ribbon Fiber, 0=Adapter |
| Output Fiber Type | L=900µm Loose tube, S=2.0mm, R=3.0mm, B=250µm Ribbon Fiber, 0=Adapter |
| Pigtail Length | 05–20=0.5–2.0m, A=Adapter, X=Others |
| Connector Type | FU=FC/UPC, FA=FC/APC, SU=SC/UPC, SA=SC/APC,ST=ST/UPC, LU=LC/UPC, LA=LC/APC,N=None, X=Others |
Performance Specifications of Planar splitter (PLC splitter)
| PLC splitter | Unit | Parameter |
| Operating Wavelength | nm | 1260~1650 |
| Typ.Insertion Loss | dB | 16.8 |
| Max.Insertion Loss | dB | 17.2 |
| Max.Uniformity | dB | 1.7 |
| Max.TDL | dB | 0.5 |
| Max.PDL | dB | 0.3 |
| Min.Return Loss | dB | 50 |
| Min.Directivity | dB | 50 |
| Operating Temperature | °C | -40~+85 |
| Storage Temperature | °C | -40~+85 |
| Package Dimensions(L×W×H) | mm | 50×7×4 |
Terms&Information:
1) Trade Terms: FOB, EX-Work.
2) Payment Terms: T/T, L/C, D/P, D/A, Western Union, MoneyGram.
3) Payment Condition: 30% deposite in advance, 70% balance after delivery.
4) Delivery Time: 4-6 working days after deposit, 3-5 working days for inventory.
5) Packing: Neutral Carton (Also can be packaged according to your requirements.)
6) Shipping: By sea, by air and by express delivery.
1.All products have been 100% tested and inspected before shipment.
2. All products have quanty warranty. If there is no man-made problem, we will replace or repair freely.
3. We provide the best after-service. If any quality problems, we will do our best to solve for customers.
1. Works as expected ".
2. " Inexpensive, great product and very easy to use ".
3. " Cheap, works perfectly ".
4. " If you are looking for adapter, do not be afraid to buy it here".
5. "Super price and very good quality."
Q1: Does ADTEK provide free samples?
A1: Yes, of course. We are glad to provide 1-3 pieces fiber optic products for our customers to compare our quality.
Q2: What is the Payment Terms ADTEK accepts?
A2: We accept L/C at sight, L/C 60 days, 30% TT deposit, 70% Balance before shipment,Western Union, Paypal, D/P, NET 30 days, NET 60 days.
Q3: Can I get any discount if I order large quantities?
A3: Yes, of course. We will provide a special price for big orders.
