bnc female adapter
- shen zhen
- T/T
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | DOSIN | |
| Model Number | DOSIN-8015 | Type | Adapter | |
| Application | RF | Gender | Female |
Product Description
Specifications
bnc connectors1,material: zinc
2,plating: gold/nickel/tin
3,high quality (ROHS)
4,bnc connectors sockets pcb mount
Features:
- Bayonet coupling, small size and low cost.
- 50Ω and 75Ω are available and intermateable
- Various options for different applications
Applications:
- Antennas
- Broadcast
- Radios
- Telecom
Electronical Specifications
Impedance | 50Ω | 75Ω |
Frequency Range | 0-4 GHz | 0-2 GHz |
Working Voltage | 500 VRMS max. at sea level | 500 VRMS max. at sea level |
Dielectric Withstanding Voltage | 1500 VRMS min. at sea level | 1500 VRMS min. at sea level |
VSWR | Straight: 1.3 max., R/A: 1.5 max. | Straight: 1.3 max., R/A: 1.5 max. |
Contact Resistance | Center Contact: 3 milliohm Max. | Center Contact: 3 milliohm Max. |
Outer Contact: 2 milliohm Max. | Outer Contact: 2 milliohm Max. | |
Insulator Resistance | 5000 megaohms min. | 5000 megaohms min. |
Material Specificions
Parts Name | Material | Finish | |
Center Contact | Male | Brass | 3u" Gold or Silver per requirement |
Female | BeCu or P. Bronze | 3u" Gold or Silver per requirement | |
Body, Metal Parts | Brass | Nickel | |
Insulators | PTFE, Delrin, PBT | None | |
Clamp Gaskets | Silicone rubber | None | |
Crimp Ferrules | Annealed copper | Nickle or Silver per requirement | |
MOQ: 500Pcs
Pckaging style: Neutral or customized packing accepted
Payment terms: We accept Paypal,T/T, Western Union ,L/C
Delivery time: 5-7 working days after payment
Shipment:
1. The parts from us are sure to have quality warranty,and they are double tested before shipping.
2. The items can be sent within 2 working day after the payment reaches us,except for mass process, we will confirm the delivery in advance.
3. We can send your order by UPS/DHL/TNT/ FedEx. Pls contact us directly and we will use your preferred ways.
4. Any import fees or charges are the buyer's responsibility. But we can help you reduce and avoid import taxes by declaring prices low, declaring the contents as "electronic accessories" or other items and shipping in simple packaging.
