EWD SOFTWARE DVD 2012D

Welcome to Electronic Wiring Diagram (EWD) for Volvo Car Corporation, EWD 2012D

New way of navigating to find the publications on the EWD!

To the left there are two dropdown lists with a number of car models.

Step 1 - select car model.

Step 2 - select a publication

The publication number is made up as follows: e.g. 39161012

39 is a function group number
The following three digits are a serial number (161)
The following two digits indicate the applicable language (01)
The final digits indicate whether the publication is a preliminary issue (1) or a definitive issue (2) of the publication.

A preliminary issue is always produced in conjunction with production start and contains information regarding fuses, relays, ground terminals and diagram pages. It is later replaced by the definitive publication, which is based on the final design documentation for the model years. It also contains updated information for the aforementioned as well as information regarding connectors, cable harness routing in vehicle, junction point information and component illustrations.
The supplement is normally issued in the Autumn and contains updated information for the different car models and is an addition to the definitive publication for each car model. Information about the changes that have been made during production, or new features that have been introduced after publication of the definitive book are published here. Supplementary information is continuously published as SPJs in TIE.

Preliminary, definitive and supplement are published on the EWD disc.
