Home > Packaging & Printing > Printing Machinery > Offset Printing Machine > Four Color Offset Printing Machine

Four Color Offset Printing Machine

Four Color Offset Printing Machine thumbnail-1
Four Color Offset Printing Machine photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Place of Origin:
Guangdong, China
Contact Supplier Request Quote Chat Now
Guangzhou Yinghe Electronic Instruments Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Flatbed Printer
Place of Origin Guangdong, China
Brand Name yinghe
Model Number YH-456C
Usage Paper Printer
Automatic Grade Automatic
Voltage 380V
Gross Power 10KW
Dimensions(L*W*H) 4.5*1.6*1.7m
Weight 1500KG
Certification CE
After-sales Service Provided Overseas service center available

Specifications

1.400x560mm printing area
2.Rapid plate loading device
3.Equipped with fault diagnosis system
4.Automatic lubrication system

four color offset printing machine

Specification

1. Over thick whole cast iron pedestal
2. Electric bevel draw plate plus intelligent plate draw system
3. Pneumatic pressure on-off
4. Rapid plate loading device
5. Import INA bearing original Germany
6. Electric control system adopts Taiwan component,10.5” color touch screen.
7. Equipped with fault diagnosis system
8. High quality alcohol tank and dampening motor has tracking function.
9. Information collection adopts digital sensors.
10. One set of special and universal tool
11. Automatic lubrication system
12. Automatic dry powder device.



four color offset printing machine

OPTIONAL DEVICE



1. Electric PS plate positioning punch machine
2. Air compressor
3. CPC ink volume remote control system
4. Automatic quick plate change device

  four color offset printing machine

Parameter

Model YH456
Max. printing size 400X560mm
Min. sheet size 210X297mm
Max. print format 505 X 345mm
Paper size  0.04-0.40mm
Max. speed 10000 pieces/hour
Speed adjustment Frequency converter
Plate size 430X560X0.15mm
Blanket size 500X560X1.90mm
Gripper margin 8-10mm
Plate loading Auto loading(optional)
Ink rollers 16pcs per unit(4 form)
Dampening Alcohol
Pile at feeder 800mm
Pile at delivery 400mm
Power supply 380V,10KW
Noise Less than 80db



four color offset printing machine

Photo detail

four color offset printing machinefour color offset printing machine

four color offset printing machine

Contact: Miss Ivy

TEL/WhatsApp/Wechat: +86 13416319493

Skype: yinghe_sale006
