High Quality 160x250cm Laser Cutter Machine

Name: High Quality 160x250cm Laser Cutter Machine
Brand: yinghe
SKU: 120114833
Availability: InStock

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Laser Type:

CO2

Applicable Material:

Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood

Guangzhou Yinghe Electronic Instruments Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Laser Type CO2

Applicable Material Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood

Cutting Thickness 20mm

Cutting Area 160x250cm

Cutting Speed 0-6400cm/min

CNC or Not Yes

Cooling Mode Water Cooling

Control Software NC studio

Graphic Format Supported PLT, DXF, BMP, Other, PLT, DXF, BMP, CDR

Place of Origin Guangdong, China

Brand Name yinghe

Model Number YH-1625

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1, working area 160x250cm
2. with 150W laser tube
3. USB connector
4. stable woring
5. can cut 20mm acrylic sheet

Optional function

Items
Electric Up and Down Table (for YH-6090, YH-1290)
Rotary attachment (for YH-6090, YH-1290)
cooling chiller CW3000
cooling chiller CW5200

Features

1.We adopt the internationally advanced DSP control technology,which arrange high-speed cutting control software,furthermore, we use USB interface to transmit data, can greatly impove working efficience.
2.Compared with domestic guide, this model used the imported AMT line which work in cloth materials.
3.Mirror and lens are made of imported fibrous material, which can endure high temperature
4.We adopt the internationally advanced DSP control technology,which arrange high-speed cutting control software,furthermore, we use USB interface to transmit data, can greatly impove working efficience.

Application material

Fabric, leather, paper, wood product, acrylic, glass, thin film, cancas, etc.

Parameter

Model				YH-1625
Engraving area				1600x2500mm
Engraving speed				0-64000mm/min (stepless speed regulating)
Laser power				120W/150W/180W
Resolution ratio				0.025mm
Minimum shaping character				Chinese character 2mm, letter 1mm
Resetting positioning accuracy				±0.01mm
Power supply				AC220V±10%, 50Hz
Gross power				<2500W
Operating temperature				0°C-45°C
Operating humidity				5%-95% (free of condensed water)
Graphic format supported				BMP, GIF, JEPG, PCX, TGA, TIFF, PLT, CDR, DWG, DXF
Net weight				480KG
Dimension				3600x2100x1100mm
Optional				Cooling machine, Honeycomb Platform
