CE approved 20-110mm PVC twin screw extruder machinery
- 0 per Month
- SHANGHAI
- T/T Credit Card
- computerized air cushion machine
- Polystyrene EPS Hot Foam Cups Machine
- HDPE water pipe production line gas pipe production line plastic HDPE pipe making machine
- HDPE PE Pipe Extrusion Making Machine HDPE water pipe production line gas pipe production line
- PVB glass laminated film production line
- PET-GRIP Cement Lining Drainage Board Production Line
Product Details
Condition: | New | Application: | Pipe | Plastic Processed: | PVC |
Screw Design: | Double-screw | Automatic Grade: | Automatical | Place of Origin: | Jiangsu, China |
Brand Name: | GRACE | Model Number: | PVC110 | Voltage: | 380/415/480V |
Power(W): | 90-120KW | Dimension(L*W*H): | 30*3*3 | Weight: | 3-4T |
Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Product Description
CE approved 20-110mm PVC twin screw extruder machinery
Machine Application
Such qualified extrusion line is mainly for producing PVC agricultural water/ building water/cable pipes, etc.
It can process various soft and rigid PVC, especially process powder directly into pipe shape.
Whole line consists of material feeder, conical twin screw extruder, die head, vacuum calibration tank, haul-off, cutter, stacker or belling machine, etc.
Machine List
No. | Item | Qty |
1 | Screw feeder | 1 set |
2 | SJZ 65/132 Conical twin screw extruder | 1 set |
3 | Die head | 1 set |
4 | Vacuum calibration tank | 1 set |
5 | Two-claws haul-off | 1 set |
6 | Saw cutter | 1 set |
7 | Stacker | 1 set |
Annotation: Some configuration and material can be designed according to customers’ requirement. | ||
Safe vedio link: 110mm PVC pipe line + Beling machine http://youtu.be/QLB7CcJ-R5s |
SJZ65/132 Conical Twin Screw Extruder
Improvements made on Conical twin screw extruder:
1.Gear box bearings: NSK, Japan
2.Gear box: Jiangyin Brand
3.Special design of screw & barrel
4. All connector, nut etc all adopt nickel plated
Electrical part:
1. Solid state relay: Crydom, USA brand instead of common AC contacto
2. Siemens PLC controlling system
3. Pressure sensor: Dynisco,USA
4. Sayu cooling fan, Taiwan brand
5. ABB550 inverter
6. Siemens Beide motor
7. Low voltage component: Siemens/Schneider/LG
Corresponding Advantages:
1. Ensuring long-time stable operation & long service life
2. Compact structure, low noise, high bearing capacity, high transmission efficiency, ensuring long-time stable operation & long service life
3. Heating is controlled by Solid State Relay (S.S.R), realizing stable heating; (SSR) no spark & no noise improve safe production.
4. Siemens PLC controlling system with reliable technology, automatic and intelligent functions for centralized control and monitoring extrusion lines, which helps easy operation.
5. International brand of electronic parts guarantee stable operation and long service life.
Die-head
Material: Pin, bush: made by 40Cr Body: Made by 40Cr, inner surface polished
Calibration sleeve: copper (1/2" 3/4" 1" with disk type calibrator)
Vacuum Calibration Tank
Vacuum pump & water pump adopt Chinese top brands.
Haul-off
Servo motors drive
Rubber block made from high grade silicone with high friction coefficient can be used for long time
Cutter
Universal clamping system, pneumatic synchronization design
chip-free cutter: high precision, no dust for good working condition, high quality alloy knife
Aluminum "HALF" clamps
Stacker
According to the pipe thickness and diameter, adopt 40 type double station coiler, 63 type single/ double station coiler, 110 type single station coiler
Servo controlled traverse unit for winding displacement,semi-automatic operation unit.
Vector frequency or moment motor control.
Other Technical Data
Extruder | Pipe ranger (mm) | Max.output (kg/h) | Max.hauling speed (m/min.) | Extruder powder (KW) |
SJZ51/105 | 16-40 Dual | 120 | 10 | 18.5AC |
SJZ65/132 | 20-63 Dual | 250 | 15 | 37AC |
SJZ51/105 | 20-63 | 120 | 15 | 18.5AC |
SJZ65/132 | 50-160 | 250 | 8 | 37AC |
SJZ65/132 | 63-200 | 250 | 3.5 | 37AC |
SJZ80/156 | 160-315 | 350 | 3 | 55AC |
SJZ92/188 | 315-630 | 800 | 1.2 | 110DC |
Auxiliary Machines
Packaging:
Depending on customers' requirement, such as wood pallet covered by plastic film
Shipping:
Our shipping operator and delivering machines will be ready on time to ensure goods shipped based on Sales Order requirement.
Our service
Please contact us in time when our service is needed after product delivery.
We'll make effective reply within 24 hours after getting call from customers.
Domestic door-to-door service is available within 24 hours.
Within 12 hours for emergency circumstances.
Abroad door-to-door service is available within 3 days after getting visa.
Within 48 hours for emergency circumstances.
Company Information of GRACE Machinery
As famous Asian plastic extrusion & recycling machine supplier with 192 lines to over 64 countries or regions.
10,000sqm warehouse, 102 staffs, 90 lines production capacity per year, including plastic pipe/profile/sheet extrusion line and consumed plastic recycling machines.
Our Customers
Certificate: CE Certificate
Fast Questions
Q: What price terms you offer?
A: FOB, CIF, EXW, L/C at sight and other price terms based on your kind request.
Q: Installation and stuff training available from you?
A: Yes, our engineers will guide machine installation and train your workers.
Q: How can we visit your company and machines?
A : Our factory is in Tangqiao Town, Zhangjiagang City, Jiangsu Province, China. About 2.5 hours from Shanghai Pudong International Ariport! We will arrange to pick you up from Shanghai.
A: Yes, our engineers will guide machine installation and train your workers.
Q: Installation and stuff training available from you?
A: Yes, our engineers will guide machine installation and train your workers.
