V Twin Cylinder 4 Stroke 688Cc Senci 22Hp Gas Engine

V Twin Cylinder 4 Stroke 688Cc Senci 22Hp Gas Engine thumbnail-1
V Twin Cylinder 4 Stroke 688Cc Senci 22Hp Gas Engine thumbnail-2
V Twin Cylinder 4 Stroke 688Cc Senci 22Hp Gas Engine photo-1
V Twin Cylinder 4 Stroke 688Cc Senci 22Hp Gas Engine photo-2
US$ 385 - 466 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Condition:
New
Usage:
Other, general machinery
Fuel:
Gasoline
Contact Supplier Request Quote Chat Now
Chongqing Senci Import Export Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Usage Other, general machinery
Fuel Gasoline
Stroke 4 Stroke
Cylinder Single Cylinder
Cold Style Other, Air-cooled
Start Electric Start
Place of Origin Chongqing, China
Brand Name Senci
Model Number SC690
Dimension(L*W*H) 510*400*565 mm
Weight 42kg
Certification CE, EPA, CARB,etc.
Warranty 1 year
After-sales Service Provided Overseas third-party support available

V Twin Cylinder 4 Stroke 688Cc Senci 22Hp Gas Engine

Top Quality 4-Stroke Small Gasoline Engine 22HP With All The Spare Parts



 V Twin Cylinder 4 Stroke 688Cc Senci 22Hp Gas Engine







Features:

* Strong two cylinder engine(OHV)

V type engine of 90 degrees angle with balance desigh of dynamic crankshaft

* Press oil pump

Press oil pump improves the lubracating of engine and extend the running hours



*High flow fun

Cooling fan of high flow reduces the tempreture of engine obviously and improves the fuction and life

* Cast iron cylinder sleeve

Withstands wear, longer engine life





Gasoline Engine specification
Model No. SC80 SC200 SC230 SC390 SC420 SC460 SC690
Engine type Single Cylinder,4 Stroke, Foced Cooling OHV Single Cylinder,4 Stroke, Foced Cooling OHV Single Cylinder,4 Stroke, Foced Cooling OHV Single Cylinder,4 Stroke, Foced Cooling OHV Single Cylinder,4 Stroke, Foced Cooling OHV Single Cylinder,4 Stroke, Foced Cooling OHV Single Cylinder,4 Stroke, Foced Cooling OHV
Bore×Stroke 48.6×43mm 68×54mm 70×58mm 88×64mm 90×66mm 92×69mm 78×72mm
Starting system Recoil/E-start Recoil/E-start Recoil/E-start Recoil/E-start Recoil/E-start Recoil/E-start Recoil/E-start
Displacement 79cc 196cc 223cc 389cc 420cc 459cc 688cc
Compression 8:5:1 8:5:1
Reted output(Kw-r/min) 2.3/4600 4.0/3600 4.6/3600 8.5/3600 9.2/3600 10/3600 12.5/3600
Max Torque/2500(N.m-r/min) 4.8/2500 11.7/2800 12.5/2800 26/2800 28/2800 29/2800 42/2500
Ignition type  CDI T.C.I
 T.C.I T.C.I T.C.I T.C.I T.C.I
Fuel Consumption(g/KW/h) ≤450 ≤374 ≤374 ≤374 ≤370 ≤370 ≤360
Dimensions(mm) 350×260×340 376×320×340 376×320×340 455×405×445 455×405×445 455×405×445 510×400×565
Net Weight(kg) 10±0.5 17±0.5 17±0.5 33±0.5 33±0.5 33±0.5 42±0.5
