Universal Full Hd Digital Satellite Tv Decoder MEELO+ ONE With Linux Os For UK
US$ 1 - 2
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Roofull
Model Number:
MEELO+ One Satellite Receiever
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Satellite TV Receiver Openbox V8S DVB-S2 V8S Set Top BoxUS$ 1 - 32MOQ: 1 Piece -
ROOFULL SV7 DLNA WEB TV HD Theater Digital Satellite ReceiveUS$ 39 - 45MOQ: 10 Pieces
-
Magic Box Internet Tv Set Top Box MagicBox MG4 HD With DVB-S2+DVB-T2+DVB-C 4K Satellite ReceiverUS$ 1 - 2MOQ: 1 Piece
-
2016 Original SOLOVOX F8S HD Digital Satellite Receiver S V8 HD Decoder Same As Sky-Box V8US$ 1 - 32MOQ: 1 Piece
-
F5S Plus Satellite Receiver With Dual Core 600MHz Processor DVB-S2 LED Display Support WEB TVUS$ 28 - 38MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
Roofull
Model Number
MEELO+ One Satellite Receiever
FTA(Free To Air)
Yes
Type
Digital
High Definition
Yes
2016 HD Satellite TV Receiver MEELO+ One with 750 DMIPS Processor DVB-S2 Tuner
| MPEG4 | High Definition MPEG4 AVC/H.264 HP@L4,MPEG-2 MP@HL/ML | ||||||||
| System | Linux Operating System | ||||||||
| DisEqc | Multiple LNB control(DISEqC)supported(DISEqC1.0,1.1,1.2and USALS) | ||||||||
| OSD Language | English German French Portuguese Spanish Italian U_Dutch Danish W_Swedish N_Finnish RUSSIAN Turkish and so on | ||||||||
| Playback | Multimedia Playback(MKV,AVI,MPG,MP4,T5,WMA,MP3 and more) | ||||||||
| Channel Search | Channel search in automatic, manual and network search | ||||||||
| Wizard | Fast and Easy installation with the installation Wizard | ||||||||
| Card | One card reader | ||||||||
| 3D | 3D ready(3D compliant Enigma 2 image installed is required) | ||||||||
| USB | Double USB (In Back Panel and Front Panel),High speed USB 2.0 | ||||||||
| Time shift | Time Shifting-Stop live television(usb hard drive required) | ||||||||
| support | YouTube videos,Internet Radios and much more,internet Streaming TV and Radio support;Ethernet Connection and WIFI/3G songle support | ||||||||
| Plugins | Easily expandable with addons and plugins | ||||||||
| Streaming | Live Streaming through metwork | ||||||||
| Management | Remote Mamagement through HTTP/Telnet/SSH/FTP | ||||||||
| Media | Media playback and recording via local network | ||||||||
| OSD | User Friendly Multilanguage Qn-Screen Display | ||||||||
| EPG | Electronic Program Guide | ||||||||
| GUI | High Resolution Graphic User Interface | ||||||||
| MODE | PAL/NTSC | ||||||||
| Skins | Skin change supported | ||||||||
| NTP | Network Time Protocol | ||||||||
| SoftUpgrade | Software upgrades through USB,Easy Software Upgrades through the Internet or through RS232 | ||||||||
| Size | L:200MM W:140MM H:40MM | ||||||||
| Button | Standby | ||||||||
| USB 2 | USB 2.0 High Speed HOST | ||||||||
| Smartcard | Smart card slot (Xcrypt and Conax embeded) | ||||||||
| LED | Green and Red | ||||||||
| IR | 38KHz | ||||||||
| Flash Memory | 256MB NAND Flash | ||||||||
| DDR2 Memory | 512MB DDR Memory | ||||||||
| CPU | 750 DMIPS Processor | ||||||||
| Demodulator IC | Integration in the main control chip | ||||||||
| Tuner Type | 1 x DVB-S2 tuners | ||||||||
| Input Frequency Range | 950MHZ-2150MHZ | ||||||||
| Input Impedance | 75Ω | ||||||||
| RF input Signal LEVEL | 65 dBm ... - 25 dBm | ||||||||
| Active Ant Power | 13/18V DC @ 400mA MAX,Overload Protection | ||||||||
| Demod standard | DVB-S2 Standard | ||||||||
| MPEG Profile Level | MPEG2 SD, MPEG2 HD, H.264/AVC SD, H.264/AVC HD,MPEG4 AVC/H264 | ||||||||
| Demodulation | QPSK, 8PSK | ||||||||
| FFT SIZE | 2K,8K | ||||||||
| Code Rate | 1/2,2/3,3/4,5/6,7/8 | ||||||||
| Guard Intervals | 1/4,1/8,1/16,1/32 | ||||||||
| DVR supporting | Stereo/MONO/Left/Right | ||||||||
| Media Supporting | Dual USB2.0 Port, USB media player to playback the media in USB flash disk or USB HDD or USB card reader with memory card. | ||||||||
| File system | FAT12, FAT16, FAT32, NTFS (only support first partition) | ||||||||
| USB2.0 High Speed HOST | DVR with USB HDD, Time shifting with USB HDD | ||||||||
| movie | mpg, avi, MKV, TS and more | ||||||||
| music | mp3,wma | ||||||||
| photo | JPG, BMP, | ||||||||
| Video Decode | High Definition MPEG4 AVC/H.264 HP@L4,MPEG-2 MP@HL/ML | ||||||||
| Aspect Ratio | Auto, 16:9 Pillar box, 4:3 Pan & Scan, 4:3 Letter Box. | ||||||||
| Video Resolution | 480I,480P, 576p, 720p, 1080i,1080P | ||||||||
| Audio Decode | MPEG1 layer I, MPEG1 layer II, MPEG1 layer III, MPEG2 AAC,MPEG4 HE-AAC | ||||||||
| Sound Mode | LEFT/RIGHT/STEREO/MONO | ||||||||
| Sampling Frequency | 32KHz,44.1KHz,48KHz | ||||||||
| Video Bandwidth | 5.5MHz(-3dB) | ||||||||
| Video Impedance | 75Ω | ||||||||
| Video Voltage Level | 1.0 Vp-p | ||||||||
| Audio Freq. Range | 20~20KHz | ||||||||
| Audio Impedance | 600Ω | ||||||||
| Audio Voltage Level | 2V rms(5.6Vp-p) | ||||||||
| Input Voltage | AC:110-240V / 50-60Hz ,DC:12V 2A | ||||||||
| Consumption | 24W Max / 1W Standby (it’s optional by customer’s board) | ||||||||
| Temperature | 0°C to +50°C | ||||||||
| Humidity | <95% | ||||||||
| Mechanical | |||||||||
| Mechanical Type | plastic + Iron | ||||||||
| Dimension | W:200mm D:140mm H:40mm | ||||||||
| Weight | 0.505kg | ||||||||
| Packing | 10 pcs | ||||||||
| Type | |||||||||
| Outline Size | 365*266*398mm | ||||||||
| Color Box Size | 252*188*68mm | ||||||||
| Color Box Weight | 0.90kg | ||||||||
| Outline SizeWeight | 10kg | ||||||||
