Specifications
ultra-thin PET double side adhesive tape, maily used for for bonding graphite film.Ultra thin PET double side tape For Graphite film
1. composition
| PET release liner (75um) |
| Acrylic adhesive layer(4um) |
| PET transparent film (1.9um) |
| Acrylic adhesive layer(4um) |
| PET release liner(25um) |
2. feature
* Ultra-thin tape design is suitable for thin applications and minimizes the thermal
conductivity of the graphite layer.
* According to design requirements, edge-covering can be applied in graphite film cutting,
endowing it with excellent electric insulation.
*Having excellent adhesion to graphite film, mobile phone panels, stainless steel heat
sinks and other base materials.
Spec. |
GC-2002-10 |
color |
Transparent, double-sided |
thickness (MM) |
0.01 |
Adhesion (N/25MM) |
≥ 8.0 |
initial adhesive (steel ball) |
3# |
Retention (h) |
≥24 |
Application |
Glue bonded |
3. Application
Ultra-thin PET double-sided adhesive tape GC-2002-10, for bonding graphite film.
| Black one sided tape GC-2001(0.01mm) |
| Graphite layer (0.012-0.1mm) |
| transparent double-sided tape GC-2002(0.01mm) |
