Home > Products > Two phase latching relay > RAMWAY RELAY DS908A-70A pulse control outlay relay,power compensation
RAMWAY RELAY DS908A-70A pulse control outlay relay,power compensation
- 100000 Piece / Pieces per Month
- Shenzhen
- T/T Credit Card
-
PPD539A102 Excitation communication controller Flexible configuration options are available
-
6ES7656-6CL33-1BF0 PLC module Supports complex control algorithms and data processing tasks
-
1394C-SJT22-A Servo controller Dc high precision power supply
-
9907-164 governor Monitor and adjust the speed of rotating machinery
-
3009X Communication module Supports multiple communication protocols
-
H90QHQE013N0 The drive has a variety of configuration options and features
Product Details
| Place of Origin: | Guangxi, China | Brand Name: | RAMWAY | Model Number: | DS908A-70A |
| Theory: | Electromagnetic Relay | Usage: | Protective | Size: | Miniature |
| Protect Feature: | Epoxy | Contact Load: | High Power |
Product Description
CONTACT DATA
Contact form | 2A & 2B |
Contact resistance | Max.2mΩ(12VDC 1A) |
Contact material | Silver alloy |
Resistance load | 70A/250VAC |
Max. switching current | 70A |
Max. switching power | 15000VA |
Electrical life | 1x104 OPS |
Mechanical life | 1x106 OPS |
CHARACTERISTICS
Insulation resistance | 1000MΩ (at 500VDC) | |
Dielectric strength | Between contact & coil | 4000VAC 1min |
Between contacts | 1800VAC 1min | |
Operation time | Max.20msec. | |
Comeback time | Max.20msec. | |
Vibration resistance | 10-55Hz, 1.5mm(DA) | |
Humidity | 98%RH, +40°C | |
Termination | PCB&QC | |
Weight | 80g | |
COIL DATA
Nominal coil voltage | Single coil resistance | Dual coil resistance |
6VDC | 20Ω | 2X10Ω |
9VDC | 36 or 55Ω | 2X18 or 2x30Ω |
12VDC | 96Ω | 2X50Ω |
|
|
|
ORDER INFO
----------------------- | DS908A | A | 70A | 9V | D | T |
Relay Model |
|
|
|
|
|
|
Connecting form | A/B/C/D/E | |||||
Terminal Type | 60A 80A 100A | |||||
Coil Voltage | 6/9/12VDC | |||||
Coil Type | Single-No mark Double-D | |||||
Contact Material | D – AgCdO12 T – AgSnO2 | |||||
Plant of latching relay
Packing
