RAMWAY RY-IS-60/80A Outdoor Switch, the Guide Rail Type, Smart Switches

RAMWAY RY-IS-60/80A Outdoor Switch, the Guide Rail Type, Smart Switches thumbnail-1
RAMWAY RY-IS-60/80A Outdoor Switch, the Guide Rail Type, Smart Switches thumbnail-2
RAMWAY RY-IS-60/80A Outdoor Switch, the Guide Rail Type, Smart Switches photo-1
RAMWAY RY-IS-60/80A Outdoor Switch, the Guide Rail Type, Smart Switches photo-2
US$ 5 - 6.5 MOQ: 200 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangxi, China
Brand Name:
RAMWAY
Model Number:
RAMWAY RY-IS-60/80A
Contact Supplier Request Quote Chat Now
Guangxi Ramway Technology Development Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangxi, China
Brand Name RAMWAY
Model Number RAMWAY RY-IS-60/80A
Theory Electromagnetic Relay
Usage Protective
Size Miniature
Protect Feature Epoxy
Contact Load High Power

CONTACT DATA

Contact form

1A & 1B

Contact resistance

Max.1mΩ(12VDC 1A)

Contact material

Silver alloy

Resistance load

90A/250VAC

Max. switching current

90A

Max. switching power

22500VA

Electrical life

1x104 cycles

Mechanical life

1x106 cycles























CHARACTERISTICS

Insulation resistance

1000MΩ (at 500VDC)

Dielectric

strength

Between contact & coil

4000VAC 1min

Between contacts

2000VAC 1min

Operation time

Max.20ms

Comeback time

Max.20ms

Vibration resistance

10-55Hz, 1.5mm(DA)

Humidity

98%RH, +40°C

Termination

PCB&QQC

Weight

42g

























COIL DATA

Nominal coil voltage

Single coil resistance

Dual coil resistance

6VDC

36Ω

-

9VDC

75Ω

-

12VDC

120Ω

-

24VDC

550Ω

-



















ORDER INFO

-----------------------

DS903C

A

90A

6V

-

T

Relay Model













Connecting form

A/B/C/D/E

Terminal Type

80A   90A

Coil Voltage

6/9/12/24VDC

Coil Type

Single-No mark

Contact Material

D – AgCdO12 T – AgSnO2

























Advantages

1.Only need pulse excitation and can be single coil working.

2.Small volume and QC installation.

3.Low power consumption and strong load capacity.

4.Security, reliable and long working life.



Note

1.Free SAMPLE for testing(1-5pcs);

2.Factory price, FOB Shenzhen;

3.Welding accessories according to clients requirement;

4.If clients have special requirement on size of other dimension, please sent us the details or drawings;

5.Delivery: within 30 days after receiving the payment(this is for MOQ, any problem or special requests, contact us).





Usage

Be fit for Prepayment energy Meter and AMR system Combination switch, reactive power compensation devices and automatic control.



RAMWAY RY-IS-60/80A outdoor switch, the guide rail type, smart switches





 OUR FACTORY



RAMWAY RY-IS-60/80A outdoor switch, the guide rail type, smart switchesRAMWAY RY-IS-60/80A outdoor switch, the guide rail type, smart switchesRAMWAY RY-IS-60/80A outdoor switch, the guide rail type, smart switches



PACKING

RAMWAY RY-IS-60/80A outdoor switch, the guide rail type, smart switches
