Safety
Design, production and testing of the generator sets comply with EU CE safety standard;
Equipped with circuit breaker to avoid possible electric risk at re- startup when engine stops in emergency.
The controller has a historical operation recording function for troubleshooting and inspection.
Powerful Engines
Adopts world-famous engines,with low noise and low emission.
Rugged structure ensures lowest vibration.
Common rail system: (for some models) significantly lowers the combustion temperature, and also leads to cleaner exhaust.
For the turbocharged machines, the carbon dioxide (CO2) emission is reduced.
Control System
Micro-processor cored digital system.
Multiple languages, automatic control.
Connected with the mains through ATS, which can help realize automatic transfer between the mains and the generators. Also, multiple generators can be paralleled for bigger power needs.
| 1. Specification of genset for China Original Weichai Deutz 20kW Soundproof Type Diesel Generator Sets | |||||||
| Gensets Model | KD-20GF | ||||||
| Prime Power(KW) | 20(25KVA) | ||||||
| Standby Power(KW) | 22(27.5KVA) | ||||||
| Rated Voltage(V) | 220 | ||||||
| Rated Current(A) | 36 | ||||||
| Rated Frequency(HZ) | 50 | ||||||
| Rated Speed (rpm) | 1500 | ||||||
| Power Factor(COS) | 0.8(lagging) | ||||||
| Prime Power(PRP):Prime power is available for an unlimited number of annual hours in variable load application,in accordance with GB/T2820-97;A 10% overload capability is available for a period of 1 hour within a 12-hour of operation. | |||||||
| Standby Power Rating(ESP):The standby power rating is applicable for supplying emergency power for the duration of a utility power interruption.No overload,utility parallel or negotiated outage operation capability is available at this rating. | |||||||
| 2. Specification of diesel engine | |||||||
| Engine brand | Deutz | ||||||
| Engine model | D226B-3D | ||||||
| Number of Cylinders | 3 | ||||||
| Cylinder arrangement | Vertical in-line | ||||||
| Cycle | Four stroke | ||||||
| Aspiration | Naturally aspirated | ||||||
| Fuel System | Direct Injection | ||||||
| Bore×Stroke (mm×mm) | 105x120 | ||||||
| Displacement (Liter) | 3.12 | ||||||
| Compression Ratio | 16.3:1 | ||||||
| Speed Governor | Mechanical | ||||||
| Cooling System | Water Cooled | ||||||
| Total lubrication system capacity (L) | 18 | ||||||
| Fuel Consumption at 100% Load (g/Kw.h) | 208 | ||||||
| Starting Method | DC24V electrical starting | ||||||
| 3. Specification of alternator | |||||||
| Alternator brand | Leroy Somer | ||||||
| Orgin | Fujian | ||||||
| Alternator model | LSAP42C | ||||||
| Number of Phase | 3 | ||||||
| Connecting Type | 3 Phase and 4 Wires | ||||||
| Number of Bearing | 1 | ||||||
| Protection Grade | IP23 | ||||||
| Altitude | ≤1000m | ||||||
| Exciter Type | Brushless ,Self-exciting, AVR automatic voltage regulating,100% Copper winding wire | ||||||
| Insulation Class | H | ||||||
| Telephone Influence Factor (TIF) | ≤50 | ||||||
| THF | ≤2% | ||||||
| Voltage Regulation, Steady State | ≤±1% | ||||||
| Transient State Voltage | ≤-15%~+20% | ||||||
China Original Weichai Deutz 20kW Soundproof Type Diesel Generator Sets
A. Exporting plywood case for optional choose if needs packaging
B. Delivery Time Detail: have generator sets in stock
Jiangsu Kangdong International Trade Co., Ltd is a professional leading Company of diesel gensets in China, We mainly supply:
Engine: Alternator: Control System:
Cummins (USA ) Original and OEM stamford Deep sea
Deutz Engine(Germany) Marathon Harson
Volvo Engine(Sweden) Engga Smartgen
Doosan Engine(Korea) ComAp
Perkins(UK) MTU(Germany)
Weichai Engine(China)
Shanghai Engine (China)
Yuchai Engine (China)
FAQ:
1.Q:What's the power range of your generator sets?
A:The main products are ranging from 5KW to 2500KW.
2.Q:How many types of the generator sets do you have?
A:Diesel,gasoline,natural gas,marine,water pump,high-voltage generator sets,etc.
3.Q:Where is your factory located?
A: Our factory is in Taizhou city, Jiangsu Province, China.
It's near Shanghai & Ningbo port.
4.Q:What is the material of your products?
A: Iron,Steel,plastic,etc.
5.Q:How about quality control in your factory?
A:"Quality is the life".
We are always paying great attentions to
quality controlling from the beginning to the end. Every piece of goods is tested strictly one by one before packing.
We keep goods to meet the standard of CE,CCC, ISO9001:2000.
China Original Weichai Deutz 20kW Soundproof Type Diesel Generator Sets
