Open type original 1200KW diesel generator set powered by MTU approved by CE
Criterion
(1) European Safety Standard: CE Certificate
(2) ISO9001:2008 Quality Control System
(3) ISO14001 Environmental Certificate
(4) Alibaba gold supplier
| Technical Specification | ||||||||
| 1. Specification of genset | ||||||||
| Gensets model | KH-1200GF | |||||||
| Prime power(KW) | 1200 | |||||||
| Rated voltage(V) | 400V/230V | |||||||
| Rated current(A) | 2160A | |||||||
| Rated frequency(HZ) | 50 | |||||||
| Rated Speed (rpm) | 1500 | |||||||
| Power Factor(COSφ) | 0.8(lagging) | |||||||
| Dimensions(mm) (L×W×H) | 6150x2150x2400 | open type | ||||||
| Genset Weight(kg) | 12000 | |||||||
| 2. Specification of diesel engine | ||||||||
| Engine brand | MTU | |||||||
| Engine model | 12V4000G23 | |||||||
| Air Intake System | Turbocharged, Air/Air Cooling | |||||||
| Fuel System | Electronic Fuel Injection System | |||||||
| Cycle | Four stroke | |||||||
| Cylinder Arrangement | 12 in “V” | |||||||
| Displacement | 57.2L | |||||||
| Bore×Stroke (mm×mm) | 170 x 210 | |||||||
| Compression Ratio | 16.0:1 | |||||||
| Cooling System | Forced Water Cooling Cycle | |||||||
| Prime power at Rated RPM | 1320KW | |||||||
| Governor Type | ADEC | |||||||
| Fuel Consumption at 100% Load (g/kwh) | 303.3 | |||||||
| Starting Method | DC24V electrical starting | |||||||
| 3. Specification of alternator | ||||||||
| Alternator brand | Kaijieli | |||||||
| Alternator model | TWGII454C | |||||||
| Exciting style | Brushless ,Self-exciting, AVR or DVR automatic voltage regulating,100% Copper winding wire | |||||||
| Number of Phase | 3 | |||||||
| Connecting Type | 3 Phase and 4 Wires | |||||||
| Number of Bearing | 1 | |||||||
| Power Factor | 0.8 | |||||||
| Protection Grade | IP23 | |||||||
| Altitude | ≤1000m | |||||||
| Insulation Class, Temperature Rise | H | |||||||
| Telephone Influence Factor (TIF) | ≤50 | |||||||
| THF | ≤2% | |||||||
| Voltage Regulation, Steady State | ≤±1% | |||||||
| Transient State Voltage | ≤-15%~+20% | |||||||
| 4. Specification of control Panel(with Kaixun controller) | ||||||||
| The control panel is AMF control panel, with the display of voltage,current, frequency, water temperature, oil pressure. The genset with low oil pressure,high water temperature,over speed,over load protection function. | ||||||||
| The features of Kaixun controller: | ||||||||
| Kaixun controller is a new generation Automatic control module for single Genset, which adopts bran-new outline configuration, focus on the requirements of customers, and perfectly improves the performance of controller. It fully meets the auto control requirements of different kinds of Genset for user or special assembly factory. | ||||||||
| The module also monitors and protects the engine, indicating operational status, fault conditions and metering on the front panel LCD and LED’s. | ||||||||
| • True RMS measure of voltage and current. | ||||||||
| • Multi-Language menu. | ||||||||
| • 128 x 64 pixel LCD display. | ||||||||
| • 4 analog inputs for kinds of optional sensors that can be used for measuring oil pressure, coolant temperature, fuel level and so on; parameters can be configured by user. | ||||||||
| • More outputs of configurable auxiliary control relays. | ||||||||
| • More configurable isolated digital inputs. | ||||||||
| • Buttons on control panel are used for selecting control modes, starting and stopping the operating procedure, displaying data and modifying the parameters. LED indicators are used for indicating the operation mode of controller and the running status of Genset, and LCD displays each measuring parameter and status. | ||||||||
| • Flexible equipped with RS485, RS232 and USB, realizing remote monitor; or communicated with PC, fully realizing functions of remote signaling, telemetering and remote control, can read and set the running parameters of controller. | ||||||||
| • With GPRS-DTU or Ethernet-DTU for remote communication instead of RS485, RS232, or USB port for remote communication. | ||||||||
| • Optional CANbus, read and control the parameters for ECU engine. | ||||||||
• All connections of the controller are by secure plug and socket, for ease and convenience to connect, move, maintain and replace the device. | ||||||||
1) Valve seat materials are imported special steel, valve use wear-resistant materials and the latest technology.
2) Piston and cylinder head production using new materials, high-performance low-emission hybrid rapid combustion cylinder. Combustion control technology to protect machine film.
3) Change the duration of the ignition control,long-life spark plugs.
4) Intergrated control diagnostics, intergrated approach to control the explosion-proof technology.
1) Valve seat materials are imported special steel, valve use wear-resistant materials and the latest technology.
2) Piston and cylinder head production using new materials, high-performance low-emission hybrid rapid combustion cylinder. Combustion control technology to protect machine film.
3) Change the duration of the ignition control,long-life spark plugs.
4) Intergrated control diagnostics, intergrated approach to control the explosion-proof technology.
1. Before-sale Service:
We provide detailed product technical parameters for equipment choosing and system designing.
2. Service quality assurance:
Our sale staffs are all experience and professional,we can provide the most proper system design and optimized equipment for the customers.
3. After sale maintenance service:
We create files for end user and provide them follow-up service,regular return visit and permanent maintenance, We have
distributors all over World that support after sale service.
4. Spare parts supply:
We provide all kinds of spare parts and technical support.
5. Main overhaul or maintenance service:
We provide perennial major overhaul and maintenance service.
Warranty
warranty is according to our standard conditions:12 months or 1,000 running hours, subject to the earlier one (artificial damage to be an exception).
1.Q:What's the power range of your generator sets?
A:The main products are ranging from 5KW to 2500KW.
2.Q:How many types of the generator sets do you have?
A:Diesel,gasoline,natural gas,marine,water pump,high-voltage generator sets,etc.
3.Q:Where is your factory located?
A: Our factory is in Taizhou city, Jiangsu Province, China.
It's near Shanghai & Ningbo port.
4.Q:What is the material of your products?
A: Iron,Steel,plastic,etc.
5.Q:How about quality control in your factory?
A:"Quality is the life".
We are always paying great attentions to
quality controlling from the beginning to the end. Every piece of goods is tested strictly one by one before packing.
We keep goods to meet the standard of CE,CCC, ISO9001:2000.
