Single Mode Double Sheath ADSS Cable Price

Name: Single Mode Double Sheath ADSS Cable Price
Brand: Hongan
SKU: 119983253
Availability: InStock

Single Mode Double Sheath ADSS Cable Price thumbnail-1

Single Mode Double Sheath ADSS Cable Price thumbnail-2

Single Mode Double Sheath ADSS Cable Price photo-1

Single Mode Double Sheath ADSS Cable Price photo-2

US$ 0.2 - 9 MOQ: 2000 Meters

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

Hongan

Model Number:

ADSS double sheath

Contact Supplier Request Quote Chat Now

Hongan Group Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name Hongan

Model Number ADSS double sheath

Specifications

1.29years experience
2. ISO9001,ISO14001
3.CE,TCL,ROHS
4. MOQ:1000M

Characteristics of product:
1.For overhead power lines such as 10kV,35kV,PE outer sheath will be used;
2.For power lines such as 110kV,220kV, AT outer sheath will be used;
3.The deliberate design of uses of aramid yarn can satisfy the demands on the conditions, such as climate, various spans and sags etc;
4.Good performance of tensile strength and temperature;

5.Small diameter and lighter of the cable reducing the load caused by ice and wind on the towers and supporting.
Applications:
area with lightning strike;
high voltage transmission systems;
aerial.
Temperature:
operating temperature:-40℃~+70℃
Standards:
IEC811,IEC60794,IEC60793
Optional:
1.the structure diameter can be designed for customers;
2.to design flame resistance, anti-rodent, anti-ant cable according to the customers' demands.

3.fiber: G.652,G.655

structural parameters:

nominal diameter	nominal weight	permitted working tensile (max.)	daily working tension(max.)	break strength	suitable span
(mm)	(kg/km)	(N)	(N)	(kN)	(m)

12.6	118	4000	1500	10	100
13.1	129	6000	220	15	150
13.4	136	8000	3000	20	200
13.6	144	10000	3600	24	250
13.9	148	12000	4400	30	270
14.2	154	14000	5200	35	300
