Utp Cat5e 24awg Network Lan Cable Made in Weihai Shandong China

Name: Utp Cat5e 24awg Network Lan Cable Made in Weihai Shandong China
Brand: Hongan
SKU: 119983081
Availability: InStock

Utp Cat5e 24awg Network Lan Cable Made in Weihai Shandong China thumbnail-1

Utp Cat5e 24awg Network Lan Cable Made in Weihai Shandong China photo-1

US$ 0.05 - 6 MOQ: 1000 Meters

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

Hongan

Model Number:

HSYV5E

Contact Supplier Request Quote Chat Now

Hongan Group Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name Hongan

Model Number HSYV5E

Specifications:

1) Resistance (max): 9.50ohm/100m at 20°C
2) D.C. resistance unbalanced (max): 2.5%
3) Mutual capacitance (max): 5.6 nF/100m
4) Capacitance unbalanced (max): 330pF/100m
5) Impedance:1-100MHz 100±15ohm
6) Differential phase delay(max):30ns/100m;
7) Operating temperature:-20~+60°C
8) Permitted bend radius:10times diameter of the cable.
9) Pairs colors: a) White/blue b) White/orange c) White/green d) White/brown
10) Materials: a) Conductor: 24 AWG copper
b) Insulation: solid HDPE
c) Sheath: PVC/PE/LSNHP

Packing:

1,000 feet (305m) per box 500m - 1000m per wooden reel Custom order lengths are available upon request

Application:

10 Base-T

100Base-T4

100Base-TX

100Base-VG-ANYLAN

155Mbps ATM

622 Mbps ATM

1000Base-T

Standards:

ISO/IEC11801

ANSI/TIA/EIA-568-B.2

Features of product:

1.more bandwith excess than 100MHz standard required;

ply with ROHS standard;

3.the products of special outer sheath or purpose can be designed according to customer's demands.

Cable structure:

Transmission performance:

frequency (MHz)	attenuation (Max) (dB/100m)	NEXT (Min.) (dB/100m)	PSNEXT (Min.) (dB/100m)	ELFEXT (Min.) (dB/100m)	RL (Min) (dB)	PHASE VELOCITY (Min)(m/s)	PHASE DELAY (Max) (ns/100m)
1	2	65	62	64	20	0.585c	570
4	4.1	56	53	52	23	---	552
10	6.5	50	47	44	25	0.611c	545
16	8.2	47	44	40	25	---	543
20	9.3	46	43	38	25	---	542
31.25	11.7	43	40	34	24	---	540
62.5	17	38	35	28	22	---	539
100	22	35	32	24	20	0.620c	538
