Sograce International Corporation Limited is a professional PCB manufacturer for producing all kinds of single side, doubleside and multilayer pcb, also provide assembly service with 10 years experience.We have a variety of advanced production equipments, excellent engineering and technical personnels, accompany with the mature management and service system.Our pcbs meet IEC,IPC,DIN,MIN standard, behaves ISO9001 quality system ,UL and Rohs certificate. Fast lead time and competitive price with high quality are our advantages. PCB lead time is within 10days,and most can be within 7days. We also established a prototype team to develop customer’s prototype needs. prototype lead time often can be within 3days.
Packing: inner vacuum packing+carton boxes
Shipping: 3-5days for sample, 12-15days after payment for large volumes
NO |
ITEM |
Technical capabilities |
1 |
Layer |
2-20layers |
2 |
Max. Board size |
2000×610mm |
|
3 |
Min. board Thickness |
2layer 0.15mm 4layer 0.38mm 6layer 0.55mm 8layer 0.80mm 10layer 1.00mm
|
4 |
Min.line Width/Space |
0.075mm(3mil) |
5 |
Max. Copper thickness |
6OZ |
6 |
Min. S/M Pitch |
0.075mm(3mil) |
7 |
Min. hole size |
0.1mm(4mil) |
8 |
Hole dia. Tolerance (PTH) |
±0.05mm(2mil) |
9 |
Hole dia.Tolerance (NPTH) |
+0/-0.05mm(2mil) |
10 |
Hole position deviation |
±0.05mm(2mil) |
11 |
Outline tolerance |
±0.10mm(4mil) |
12 |
Twist & Bent |
0.75% |
13 |
Materials |
FR4,H-TG,Teflon,Rogers,Ceramics,Aluminium
|
14 |
Electric strength |
>1.3kv/mm |
15 |
S/M abrasion |
>6H |
16 |
Thermal stress |
288℃ 20Sec |
17 |
Test Voltage |
50-300V |
18 |
Min. blind/buried via |
0.15mm (6mil) |
19 |
Surface Finished |
HASL, ENIG, ImAg, Imsn OSP, Plating AG, Plating gold |
Product Show
1.Circuit board assembly fabrication: One-stop pcb assemblies service, PCB design, PCB layout, PCB manufacturing, PCB Assemblies, components sourcing, PCBA Function Test, design solutio
2.Quote Needed: 1.PCB Gerber File; 2.Bom List for PCB Assembly; 3. Send us a sample of PCBA to make the exactly same for you. 4. Test Method for PCB Assembly.
3.PCB+COMPONENTS+SMT the whole service with top quality and very competitive price for you; OEM design and custom made products are welcomed.
PCB manufacturer Sograce provice pcb board with pcb assembly
