Centrifugal Sieving Machine for Flour/starch

Specifications

1.It is stable in operation
2.Free of vibration and little noise
3.Excellent sealing performance
4.No dust pollution

Features:

1.The whole machine is small in size and light weight so that it is stable in operation, free of vibration and little noise. With its excellent sealing performance, it is no dust pollution and can gain a high screening efficiency.

2.The updated apperance design of this machine makes it easy to install and convenient to operation.

3.The machine can operate either in single unit or in multiple units, and it is safe and reliable for long time operation. This machine not only can be operated in single unit, it can also be operated in multiple unit. With its reliable quality and safe operation, this machine can gain a long service life.

4.The screen-cloth can be cleaned automatically by cyclone, and the machine has the funcition of re-crashing the agglomeration material.



Working Principle:

The cylinder screen-mesh of this device is placed the base machine. The materials mixed with airflow and atomization pass the screw conveyor device, enter the net tube. The undersize materials are sprayed through the screen cloth and diacharged from the fine stuff outlet under the action of centrifugal force and cyclone propelling power, which caused by the rotor vane inside the net tube. The oversize material, which can not cross the net, is discharged from the rough material outlet along inside surface of the tube.



Scope of Application:

The material is available in the industries such as metallurgy, mining, pharmacy, food, chemical, metal powder and nonmetal etc.



Technical Parameter:

Model	Body Material	Application
BL 18-65	SUS304 or Carbon steel	500 mesh below
BL 30-100		325 mesh below
BL 50-130		300 mesh below



Machine Picture:
