High Quality and Low Price CNG Hoop Wraped Steel Lined Cylinder for Cars
|
Name |
Type II CNG steel liner hoop-wrapped with glass fiber cylinder |
Manufacturing STD |
ISO11439, ISO9809, NZS5454, NGV2, ECE R110 |
|
Outer diameter |
325mm, 356mm, 406mm |
|
Water capacity |
50L-200L |
|
Working pressure |
20MPA |
CNG Cylinder for Vehicle
SinoCleansky specializes in providing a comprehensive solution of NGV, covering various products and services. Particularly, SinoCleansky has a strong advantage in providing the essential part of NGV, the high pressure CNG cylinder, which is used to store the compressed natural gas on board the vehicle or as back-up storage as cascade cylinders. SinoCleansky CNG cylinders are manufactured as per different international standards, principally ISO11439, NZS5454, NGV2-2000 and etc. Our productions have been certified by the international third-party authorities including LRS, BV, SGS, DOT etc.If you focus on CNG composite cylinder, especially for CNG cylinder type 3, SinoCleansky will be your excellent professional supplier. We can provide:
Type I CNG steel cylinder for vehicle
Type II CNG composite cylinder for vehicle (steel liner hoop-wrapped with glass fiber)
Type III CNG composite cylinder for vehicle (aluminum liner fully-wrapped with carbon fiber)
CNG storage cylinder for cascade, both type I and type II and type III
Main types
Standard |
Type |
Liner Outside Diameter (mm) |
Composite Cylinder Outside Diameter (mm) |
Water Capacity (L) |
Height (mm) |
Weight (kg) |
Service Pressure (MPa) |
ISO11439 |
CRP356-ISO-57 |
356 |
370 |
57 |
800 |
51 |
20 |
ISO11439 |
CRP356-ISO-65 |
356 |
370 |
65 |
875 |
56 |
20 |
ISO11439 |
CRP356-ISO-75 |
356 |
370 |
75 |
990 |
61 |
20 |
ISO11439 |
CRP356-ISO-145 |
356 |
370 |
145 |
1755 |
109 |
20 |
ISO11439 |
CRP406-ISO-100 |
406 |
420 |
100 |
1025 |
84 |
20 |
ECE R110 |
CRP356-R110-57 |
356 |
370 |
57 |
800 |
51 |
20 |
ECE R110 |
CRP356-R110-65 |
356 |
370 |
65 |
875 |
56 |
20 |
ECE R110 |
CRP356-R110-75 |
356 |
370 |
75 |
990 |
61 |
20 |
ECE R110 |
CRP356-R110-145 |
356 |
370 |
145 |
1755 |
109 |
20 |
ECE R110 |
CRP406-R110-100 |
406 |
420 |
100 |
1025 |
84 |
20 |
