Fixed Forks Semi Electric Hydraulic Stacker

Name: Fixed Forks Semi Electric Hydraulic Stacker
Brand: JIALIFT
SKU: 119897175
Availability: InStock

US$ 1,070 - 1,307 MOQ: 1 Unit

Key Specifications

Condition:

New

Place of Origin:

Zhejiang, China

Brand Name:

JIALIFT

Zhejiang Jialift Warehouse Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Zhejiang, China

Brand Name JIALIFT

Model Number SPN10

Type Other, semi electric stacker

Power Souce DC Motor

Rated Loading Capacity 1000kg

Max. Lifting Height 3.5m

Min. Lifting Height 85mm

Fork Length 900/1100mm

Fork Width 150mm

After-sales Service Provided Engineers available to service machinery overseas

Product Description

Identification	1.1	Model		SPN1016	SPN1020	SPN1025	SPN1030		SPN1035
	1.2	Operate type		Pedestrian
	1.3	Drive		Electric
	1.4	Load capacity	kg	1000
	1.5	Load capacity. Fork’s highest point		1000	800	700	600	500
	1.6	Load center distance	mm	450
Weight	2.1	Service weight	kg	362	366	374	398	442
Wheels	3.1	Tyres		PA
	3.2	Axle loading, laden rear	mm	Φ180×50, 2 pcs
	3.3	Axle loading, laden front	mm	Φ74×70, 2 pcs
Size	4.1	Lift height	mm	1600	2000	2500	3000		3500
	4.2	Height lowered fork	mm	85
	4.3	Overall length	mm	1600/1800
	4.4	Overall width	mm	760
	4.5	Fork length	mm	900/1100
	4.6	Outside width	mm	Short leg truck 550-830, wide leg truck 330-640
	4.7	Single fork width	mm	150
	4.8	Turning radius	mm	1350
Performance data	5.1	Lift speed, laden/unladen	m/s	84/133
	5.2	Lowering speed. Laden/unladen	m/s	94/72
	5.3	Service brake		Wheel brake
E-motor	6.1	Lift motor	kw	1.5
	6.2	Battery voltage, nominal capacity	V/Ah	12/120
	6.3	Battery type		Industrial battery
