Custom Wholesale High Quality CNG Jumbo Tube Skid/CNG Tube Trailer

Custom Wholesale High Quality CNG Jumbo Tube Skid/CNG Tube Trailer thumbnail-1
Custom Wholesale High Quality CNG Jumbo Tube Skid/CNG Tube Trailer thumbnail-2
Custom Wholesale High Quality CNG Jumbo Tube Skid/CNG Tube Trailer thumbnail-3
Custom Wholesale High Quality CNG Jumbo Tube Skid/CNG Tube Trailer thumbnail-4
Custom Wholesale High Quality CNG Jumbo Tube Skid/CNG Tube Trailer thumbnail-5
Custom Wholesale High Quality CNG Jumbo Tube Skid/CNG Tube Trailer thumbnail-6
Custom Wholesale High Quality CNG Jumbo Tube Skid/CNG Tube Trailer photo-1
Custom Wholesale High Quality CNG Jumbo Tube Skid/CNG Tube Trailer photo-2
Custom Wholesale High Quality CNG Jumbo Tube Skid/CNG Tube Trailer photo-3
Custom Wholesale High Quality CNG Jumbo Tube Skid/CNG Tube Trailer photo-4
Custom Wholesale High Quality CNG Jumbo Tube Skid/CNG Tube Trailer photo-5
Custom Wholesale High Quality CNG Jumbo Tube Skid/CNG Tube Trailer photo-6
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Max Payload:
5760KG
Size:
OD559*17.4*10975
Place of Origin:
China
Contact Supplier Request Quote Chat Now
Beijing Sinocleansky Technologies Corp.
Payment & Shipping
Payment Methods:
Port of Shipment:
Main Port China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Max Payload 5760KG
Size OD559*17.4*10975
Place of Origin China
Brand Name SINOCLEANSKY
Model Number SCS0825CT-40F

Custom Wholesale High Quality CNG Jumbo Tube Skid/CNG Tube Trailer

Custom Wholesale High Quality CNG Jumbo Tube Skid/CNG Tube Trailer





Specification



Model No.

SCS0825CS-40F

SCS0825CT-40F

SCS1025CT-40F

SCS1225CS-40F

Cylinder quantity

8

8

10

12

Working pressure/MPa

25

25

25

25

Cylinder size/mm

OD559*17.4*10975

OD559*17.4*11580

OD559*17.4*11580

OD559*17.4*10975

Steel type

4130X/30CrMo

4130X/30CrMo

4130X/30CrMo

4130X/30CrMo

Working temperature

-20~65℃

-20~65℃

-20~65℃

-20~65℃

Cylinder weight/KG

2825

2981

2973

2825

Equipment weight /KG

25860

26200

33920

37260

Water volume/M3

17.8

19.1

23.33

27

Filling gas volume /NM3

5300

5680

7000

8030

Loading weight/KG

3800

4075

5019

5760

Total weight/KG

29660

30275

38939

43020

Skid/Trailer dimension

12192*2438*1400

12192*2438*1400

12192*2438*2071

12192*2438*2010

(skid)

(skid)

(skid)

(skid)







Characteristics

CNG jumbo tube skid

 Ideal Solution for CNG Storage and Transportation---CNG Jumbo Cylinder Skid/Trailer

 Produce as per ISO11120, ASME and approved by BV inspection report.

 Application:

 SinoCleansky CNG jumbo cylinder /high pressure jumbo cylinder are widely used in sectors of gas storage, NGV station, CNG transportation, and CNG power generating plant and etc. Meanwhile our jumbo cylinder/high pressure jumbo cylinder are also applied for the storage and transportation of hydrogen, oxygen, nitrogen, argon, helium, purified gas and other kinds of gases.

 Features of SinoCleansky high-pressure jumbo gas cylinder:

 1. Heat-spinning technology;

 2. Walking beam continuous heat treatment;

 3. Large-size structure and fewer valves, tubes and joints;

 4. Concise design, less maintenance on site;

 5. Lower weight of design;

 6. Additional gas-filling devices.
