Home > Transportation > Forklifts & Parts > Forklift > 1000KG Pedestrian Full Electric Stacker CL15

1000KG Pedestrian Full Electric Stacker CL15

Name: 1000KG Pedestrian Full Electric Stacker CL15
Brand: JIALIFT
SKU: 119895151
Availability: InStock

1000KG Pedestrian Full Electric Stacker CL15 thumbnail-1

1000KG Pedestrian Full Electric Stacker CL15 photo-1

US$ 3,478 - 4,307 MOQ: 1 Unit

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Zhejiang, China

Brand Name:

JIALIFT

Contact Supplier Request Quote Chat Now

Zhejiang Jialift Warehouse Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Zhejiang, China

Brand Name JIALIFT

Model Number 1 Ton load capacity electric stacker

Type Other, Full electric stacker

Power Souce DC Motor

Rated Loading Capacity 1000kg

Max. Lifting Height 3.6m

Min. Lifting Height 86mm

Fork Length 1150mm

Fork Width 180mm

Specifications

High performance hydraulic power unit, combined DC motor, gear pump. Value disc and pipe components.

The specification of Two door frame full electric hydraulic stacker 1TON

Identification	1.1	Model		CL1016		CL1026	CL1032		CL1036
	1.2	Operate type		Pedestrian
	1.3	Drive		Electric
	1.4	Load capacity	kg	1000
	1.5	Load capacity. Fork’s highest point		1000	800			700	600
	1.6	Load center distance	mm	600
Weight	2.1	Service weight	kg	680	860			890	920
Wheels	3.1	Tyres		Polyurethane wheels
	3.2	Axle loading, laden rear	mm	Φ250×78, 2 pcs
	3.3	Axle loading, laden front	mm	Φ80×70, 4pcs
Size	4.1	Lift height	mm	1600		2600	3200		3600
	4.2	Height lowered fork	mm	85
	4.3	Overall length	mm	1893
	4.4	Overall width	mm	805
	4.5	Fork length	mm	1150
	4.6	Outside width	mm	570/695
	4.7	Single fork width	mm	180
	4.8	Turning radius	mm	1460

1, High performance hydraulic power unit, combined DC motor, gear pump. Value disc and pipe components.

2, With small size, high reliability, stable work, energy conservation, noise reduction, environmental protection, etc.

3, Electronic control system which is imported from US Curtis is responsive, good manipulation, automatic regeneration, reverse connect braking and wireless control, and other functions.
