Automatic Biomass Pellets Packing Line With Robot Palletizer Stacking on Pallet

Specifications

Application:

It is automatic filling and packaging system,   automatic biomass pellets packing line with robot palletizer  ,  automatic bagging palletizing system ,   automatic bagger scale and palletizing machine,  Automated packing system, Automatic Packing Machine, automated packaging line, automated bagging palletizing machine, automated bagging packaging palletizing line, full automated packing line that applicable for packing granular or particulate materials such as rice, wheat, grains, pellets, salt,  phosphate, fertilizer, compost, urea, SSP, NPK, mineral powder, ore fines, etc. automatic packing machine with CE, ISO9001-2008, CQC

And also the automatic robot palletizer and pallet stretch wrapping machine are optional for the complete automatic packing machine automatic packaging stacking and pallet stretch wrapping line. automatic packing machinery

Main Component:

1. Automatic quantity-fixed balance

2.Automatic bag-supplying and weighing filling section

3. Optional section such as air compressor

4.Automatic bag-clamped section

5. Automatic belt conveyor

6.Automatic sewing or sealing machine

7. Automatic bag-backwards section

8. Automatic robot palletizing machine for option

9. Automatic online pallet stretch wrapping machine for option

10. Electrical PLC instrument control cabinet

Characteristic:

1. Picking bag, feeding bag, filling material, weighing, sewing or sealing bag, bag-backwards and bag transmission are finished completely automatically. Optional automatic palletizing, pallet stretch wrapping.

2. Adopting PLC to guarantee the reliability of control

3. Adopting high-precision transducer and intelligent instrument to guarantee the accuracy and speed of weight

4. Adopting touch screen with trouble display and help system for easy operation.

5. Adopting imported pneumatic components features compact structure, reliable performance and convenient maintenance.

6. The sewing / sealing machine is imported NEWLONG brand machine from Japan.

Main Technical Parameter:

Model: MZDP , automatic packing machine system

Packing Scope: 1~5, 5~10, 10~25, 25~50 (KG) (adjustable as per requirement)

Weight Accuracy: ±0.2%FS

Packaging Material: Open mouth bag

Bag Size: 950×650mm(adjustable as per different weight )

Air Pressure: 0.6 (Mpa)

Air Consumption: 0.7 (m3/min)

Power: 8~16 (KW)

Total weight: 25000 (KG)

Company Information

Wuxi M&J Machinery Engineer Co., Ltd is one of the most professional manufacturers specialized in all kinds of packing machine and conveyor that used for packing and conveying plenty of powder, pellet, granules, etc. With the good market positioning and professional manufacturing technologies, Wuxi M&J Machinery Engineer Co., Ltd. will surely provide you with the most professional products and service.

Certificate and Honors

M&J Machinery as a leading manufacturer in packing machine industries, we got many honors and certificate and ensure the products with export standard.

Quality Control

Highly skilled and educated employees manufacture products with world-famous brands equipments. Quality management system follows ISO9001, and our products are with CE, CQC, CIQ certificate.

Clients visit

M&J Machinery warmly welcome all clients to visit the factory and office to inspect goods before placing order and before delivery.

Packaging & Shipping

With advanced delivery process, make sure equipments delivered to buyer's jobsite on time and safety.

Oversea Service

With advanced technology and prompt service, we have built long business relations with world customers more than 100 countries, such as Saudi Arabia, UAE, Iran, South Korea, Pakistan, Russia, India, Indonesia, Malaysia, Singapore, USA, Australia, Fiji, Sweden, Latvia, Chile, Ecuador, Peru, Mexico, Bahamas, Panama, Jamaica, Egypt, Mali, etc.
