Fiberglass Sucker Rod

Name: Fiberglass Sucker Rod
Brand: TID Tech
SKU: 119892575
Availability: InStock

US$ 10 - 20 MOQ: 100 Pieces

Key Specifications

Place of Origin:

China

Brand Name:

TID Tech

Model Number:

FSR-0013

Weinan TID Technology Development Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao/Tianjing/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name TID Tech

Model Number FSR-0013

Type Light Crude Oil(LCO)

Application Base Oil

Grade Other

Chemical Composition fiberglass

1.Advantage of Fiberglass Sucker Rod

Modulus of Elasticity	Longer Run Time	Increasing Output
	Maintain Well Flow
	Increased Downhole Pump Stroke
Corrosion Resistant	Less Down Time	Less Capital Expenses
	Less Servicing
	Less Replace Costs
Light Weight	Smaller Structure	Energy Savimg
	Smaller Counter Weights
	Smaller Gearbox
	Smaller Motor
	Improwed Efficiency

1.Applied Standard: API Spec 11B SY/T 5029-2006

2.Dimension of the Fiberglass Sucker Rod

Diameter	7/8″ (22)mm	1 ″ (25mm)	1 ¼ ″ (32mm)
Length	813mm~11328mm

4.Connection Fitting class: A class.

5.Elastic Modulus: 496×102MPa(7.2×106psi)

6.Technical Specification:

ROD SIZE		22(7/8″)	25(1″)	32(1 1/4″)
ROD BODY DIAMETER(±0.015)		.875″	1.00″	1.25″
WEIGHT PER FT (including coupling) (LBS/FT)	30′	0.7132	0.9224	1.4631
WEIGHT PER FT (including coupling) (LBS/FT)	37.5′	0.6793	0.8787	1.3897
COUPLING SIZE		3/4″	7/8″	1″
END FITTING DIAMETER(+0.005)(-0.010)		1.490″	1.615″	1.990″
WRENCH		1.0″	1.0″	1-1/8″
ELEVATORS		1.0″	1.0″	SPECIAL
MAX END FITTING TENSILE STRENGTH(PSI)		115,000	115,000	115,000
MAX WORKING LOAD(LBS)		20,000	27,000	42,000
MAX WORKING STRESS(PSI)		35,000	35,000	35,000
MAX SHORT TERM LOAD(LBS)		31,500	41,000	65,000
MAX SHORT TERM STRESS(PSI)		53,000	53,000	53,000
MAX DESIGN TEMP(℉)		240	240	240
