Flameproof/Explosion-proof/Anti-explosion LED Induction Lamp Of Roadway

1.Product  Feature

BLEDD3-series LED explosionproof lamp applies to Zone 1and 2, ⅡA,ⅡB type T5~T6 group explosive gas or steamy environment with AC50Hz,rated voltage 220V below 250W rated power as workshop or site lamp.

2. Product Environment

1.Environment air pressure is 86~106 kPa;

2.Ambient temperature is -20~+40℃;
3.Air relative humidity is not higher than 85%(under+2
4.It applies to Zone 1 and 2, ⅡA,ⅡB type T5~T6 group explosive gas or steamy environment;
5.In a place free of concentrated corrosive gas,steam and dust damaging metal or insulation property;
6.In a place free of violent shake or impact vibration;
7.In a place where immersion into other liquid can be prevented;
8.Pollution degree 3;
9.Installation type Ⅱ type;

3.Product  parameter

The main technical parameters:

Power	Curren(mA)	Voltage(V)	Flux(lm)	CCT(k)	CRI	Lamp Luminous Efficiency(lm/w)	Picture
3W	300	9~10	280	6000	Ra75	>90
4W	300	12~13.5	370	6000	Ra75	>90
5W	300	15~17.5	450	6000	Ra75	>90
7W	300	21~24.5	650	6000	Ra75	>90
9W	300	27~31.5	820	6000	Ra75	>90
10W	300	30~35	900	6000	Ra75	>90
15W	750	18~21	1500	6000	Ra75	>90
20W	600	30~35	1800	6000	Ra75	>90
30W	750	36~42	3200	6000	Ra75	>90
