1.Product Feature
BLEDD1-series LED explosionproof lamp applies to Zone 1and 2, ⅡA,ⅡB type T5~T6 group explosive gas or steamy environment with AC50Hz,rated voltage 220V below 150W rated power as workshop or site lamp.
2. Product Application
BLEDD1-series LED explosionproof lamp applies to Zone 1and 2,ⅡA,ⅡB type T5~T6 group explosive gas or steamy environment with AC50Hz,rated voltage 220V below 150W rated power as workshop or site lamp.
3. Application area
| Product Type | Light Source Type |
Voltage | Power |
Protection Degree |
Protection Sign |
Corrosionproof Degree |
OuterCableDia(mm) |
| BLEDD1-50 | LED Light Source |
220 |
50 | IP65 |
ExdⅡBT6 |
WWF1 |
10~14 |
BLEDD1-70 |
70 | ||||||
| BLEDD1-90 | 90 | ||||||
| BLEDD1-120 | 120 | ||||||
| BLEDD-150 | 150 |
The main technical parameters:
| Power | Curren(mA) | Voltage(V) | Flux(lm) | CCT(k) | CRI | Lamp Luminous Efficiency(lm/w) | Picture |
| 3W | 300 | 9~10 | 280 | 6000 | Ra75 | >90 | |
| 4W | 300 | 12~13.5 | 370 | 6000 | Ra75 | >90 | |
| 5W | 300 | 15~17.5 | 450 | 6000 | Ra75 | >90 | |
| 7W | 300 | 21~24.5 | 650 | 6000 | Ra75 | >90 | |
| 9W | 300 | 27~31.5 | 820 | 6000 | Ra75 | >90 | |
| 10W | 300 | 30~35 | 900 | 6000 | Ra75 | >90 | |
| 15W | 750 | 18~21 | 1500 | 6000 | Ra75 | >90 | |
| 20W | 600 | 30~35 | 1800 | 6000 | Ra75 | >90 | |
| 30W | 750 | 36~42 | 3200 | 6000 | Ra75 | >90 |
| Type | Current(mA) | Voltage(V) | Flux(lm) | CCT | CRI | Lamp Luninou Efficeiency(lm/w) |
| 3528 | 20 | 3.0~3.4 | 7~9 | 6000 | 80 | 130 |
| 3014 | 30 | 3.0~3.4 | 9~11 | 6000 | 80 | 130 |
| 2835 | 40 | 3.0~3.4 | 14~17 | 6000 | 80 | 140 |
| 5050 | 60 | 3.0~3.4 | 18~22 | 6000 | 80 | 130 |
