Help CenterAutomatic Bagging Machine With Bag Pushing System
Related Products
Application:
It is packing machine packaging machinery automated packaging machine, Automatic bagging machine with bag pushing system , Automatic weighing system with bag pushing system , sugar automatic packing machine , Automated packing system, Automatic Packing Machine, automated packaging line, automated bagging palletizing machine, automated bagging packaging palletizing line, full automated packing line that applicable for packing granular or particulate materials such as grain, rice, wheat flour, starch, wood pellet, granules, animal feed, prilled urea, phosphate, PP, PE, salt, flour, wheat bran, sand, mineral powder, ore fines, sand, resins, pvc powder, cement + sand + additive, dry mortar powder, etc. automatic packing machine with CE, ISO9001-2008, CQC, automatic packing machinery
And also the automatic robot palletizer and pallet stretch wrapping machine are optional for the complete automatic packing machine automatic packaging stacking and pallet stretch wrapping line. automatic packing machinery
Main Component:
1. Automatic quantity-fixed balance
2.Automatic bag-supplying and weighing filling section
3. Optional section such as air compressor
4.Automatic bag-clamped section
5. Automatic belt conveyor
6.Automatic sewing or sealing machine
7. Automatic bag-backwards section
8. Automatic robot palletizing machine for option
9. Automatic online pallet stretch wrapping machine for option
10. Electrical PLC instrument control cabinet
Characteristic:
1. Picking bag, feeding bag, filling material, weighing, sewing or sealing bag, bag-backwards and bag transmission are finished completely automatically. Optional automatic palletizing, pallet stretch wrapping.
2. Adopting PLC to guarantee the reliability of control
3. Adopting high-precision transducer and intelligent instrument to guarantee the accuracy and speed of weight
4. Adopting touch screen with trouble display and help system for easy operation.
5. Adopting imported pneumatic components features compact structure, reliable performance and convenient maintenance.
6. The sewing / sealing machine is imported NEWLONG brand machine from Japan.
Main Technical Parameter:
Model: MZDP , automatic packing machine system
Packing Scope: 5~10, 10~25, 25~50 (KG) (adjustable as per requirement)
Weight Accuracy: ±0.2%FS
Packaging Material: Open mouth bag
Bag Size: 950×650mm(adjustable as per different weight )
Air Pressure: 0.6 (Mpa)
Air Consumption: 0.7 (m3/min)
Power: 8~16 (KW)
Total weight: 25000 (KG)
automatic packing machinery
automatic packaging line bagging line
automatic packing machine
automatic packaging machinery
automatic packing machinery
