Specifications
200 square millimeter Electric Round Aluminum Rod1. passed CE,ISO,CCC,PCCC...certificate
2.sell well in Europe, America, Asia
ACSR
1.Product standard: GB/T3954-2001
According to the requirement of wide customer our company can produce aluminum single wire and bared wire, etc with any specification.
2.Type status and specification
Type |
Status |
Diameter mm |
A2 A4 A6 A8 |
H112 |
9.5±0.5 |
3.Mechanical and electric property of aluminum rod
Type |
MPa Tensile resistance |
Rate of elongation≥ |
D.C. resistance≤ |
A2 |
80~110 |
12 |
27.85 |
A4 |
95~115 |
10 |
28.01 |
A6 |
110~130 |
8 |
28.01 |
A8 |
120~150 |
6 |
28.01 |
4.Diameter deviation
Diameter deviation of electric round aluminum rod and the elasticity should be in conformity with the regulations in following list:
diameter |
Error |
Elasticity not more than |
9.0~12.0 |
±0.5 |
0.9 |
13.5~20.0 |
±0.7 |
1.2 |
Note: The elasticity is the difference between Max diameter and Min diameter measured at same cross section while aluminum rod is perpendicular to axial line.
5.Surface quality
- Electric round aluminum rod should be round and the size should be uniform.
- The surface of electric round aluminum rod should be clean, without defects such as wrinkle, stagger round, crack, impurity, kink, etc as well as other defect that is harmful to application. The light mechanical scratch, spot, pit, peeling or black spot, etc are permitted.
6.Delivery weight
- Electric round aluminum rod should be delivered by reel. Each reel will be over 1000kg.
- According to the agreement signed by both parties, electric round aluminum rod with any weight can be delivered.
