Clip on Guinean Genset for 20feet Reefer Container for Prey Veng

Name: Clip on Guinean Genset for 20feet Reefer Container for Prey Veng
Brand: ISUZU
SKU: 119861055
Availability: InStock

US$ 4,000 - 7,000 MOQ: 5 Units

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

ISUZU

Model Number:

4JB1

Zhejiang Universal Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo/ Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name ISUZU

Model Number 4JB1

Output Type AC Three Phase

Speed 1800 RPM

Frequency 60 Hz

Rated Power 24kw

Rated Voltage 460V

Rated Current 34A

Specifications

Clip on Guinean genset for 20feet reefer container for Prey Veng
1.Isuzu engine
2.Vigor alternaotor
3.LCD Display
4.390L tan

Clip on Guinean genset for 20feet reefer container for Prey Veng

Manufactured by Zhejiang Universal Machinery Co.,Ltd

Genset Model			25ESX
SET	Rated power(Kw/kva)		20/25
	Frequency(Hz)		50
	Pahse		3
	Voltage(V)		230/400
	Current(A)		36
	Fuel capacity(L)		82
	Fuel consumption(L/Hour)		5.8
	Dimension (mm)	L	2000
		W	850
		H	1120
	Weight(kg)		770
	Noice level for silent type (Db/7m)		65
ENGINE	Model		4JB1
	Prime power(kw/kva)		24/30
	Cylinders		4
	Bore×stroke(mm)		93×102
	Intake Method		Natural intake
	Displacement(L)		2.771
	Speed governing		Mechanical governor
	Cooling starting method		Water cooling
ALTERNATOR	Model		DG184F
	Rated power(kw/kva)		22/27.5
	Insulation class		H
	Alternator enclosure		IP23
THIS SET COULD BE OPERATED ON 100% OF THE POWER CAPACITY AT ALTITUTE OF 1500M, AMBIENT TEMPERATUR OF 50°C. WE RESERVE THE RIGHT TO EXPLAIN THE TERMS OF THIS SPECIFICATION.
