Help CenterTransport 20KVA DIESEL Generator
Related Products
-
Transport 30KVA Diesel GeneratorUS$ 5,000 - 6,000MOQ: 5 Units -
Transport 40KVA Clip on DIESEL GENERATORUS$ 5,000 - 6,000MOQ: 5 Units
-
HOT SALE 40KVA Clip on DIESEL GensetUS$ 5,000 - 6,000MOQ: 5 Units
-
HOT SALE 30KVA Clip on DIESEL GensetUS$ 5,000 - 6,000MOQ: 5 Units
-
Hot Sale Transport 40KVA Clip on Diesel GensetUS$ 5,000 - 6,000MOQ: 5 Units
Specifications
transport 20KVA DIESEL generator1.ISUZSU engine
2.Vigor alternaotor
3.smartgen AMF
4.clip on.1year warranty
transport 20KVA DIESEL generator
Genset Model |
20ESX |
||
SET |
Rated power(Kw/kva) |
16/20 |
|
Frequency(Hz) |
60 |
||
Pahse |
3 |
||
Voltage(V) |
460 |
||
Current(A) |
78.9 |
||
Fuel capacity(L) |
56 |
||
|
Fuel consumption(L/Hour)
|
7 |
||
Dimension (mm) |
L |
2000 |
|
W |
850 |
||
H |
840 |
||
Weight(kg) |
790 |
||
Noice level for silent type (Db/7m) |
65 |
||
ENGINE |
Model |
4L22BD |
|
Prime power(kw) |
31 |
||
Cylinders |
4 |
||
Bore×stroke(mm) |
93×102 |
||
Intake Method |
Turbo Charge |
||
Displacement(L) |
2.771 |
||
Speed governing |
Mechanical governor |
||
Cooling starting method |
Water cooling |
||
ALTERNATOR |
Model |
DG184G |
|
Rated power(kw/kva) |
25/31.3 |
||
Insulation class |
H |
||
Alternator enclosure |
IP23 |
||
THIS SET COULD BE OPERATED ON 100% OF THE POWER CAPACITY AT ALTITUTE OF 1500M, AMBIENT TEMPERATUR OF 50°C. WE RESERVE THE RIGHT TO EXPLAIN THE TERMS OF THIS SPECIFICATION. | |||
Certificate:CE,ISO,SONCAP COC etc
Certificate: SGS,CE,ISO and Soncap,GOST-R ,more options offer
Want more detailed specification or pictures for our mute diesel genset, please contact us
