Specifications
Automatic Sleeve Labeling Machine 1501. PET/glass bottle
2. 150bpm
3. ISO, SGS, CE, GMC
Automatic Sleeve Labeling Machine 150
Features:
All-cover type stainless steel host machine: the whole machine is waterproof as well as rustproof.
Adjustable cutter head: unique cyclotron cut-off, double sided cutting edge with a long service life.
Single positioning centre guide pillar: more stable for label delivery.
Synchronous bottle divider: a more stable transmission for the bottle.
Bottom set label brush: more precision for casting label.
Label-controlling electric-eye shelf: unique combination of tail and electric-eye to improve the precision for cutting off the membrane materials.
Push-button control cabinet: a more humanized operation.
Independent feeding material shelf: the position of the material shelf is optional at will.
Electrical Appliance Configuration Specification
It adopts PLC programmable controller, imported servo motor, servo driver, frequency converter and transducer; also, it adopts the positioning module to ensure the casting label precise, rapid and stable.
Applicable Variety Types of Label
Various kinds of bottle types, for example: round bottle, square bottle, flat bottle, curve bottle and cup-shaped, etc.
| SLM-150/250 | Technical Parameters | |
| Model | SLM-150 | SLM-250 |
| Input Power | 1.5KW | 3.0KW |
| Input Voltage | D3,380/220VAC | D3,380/220VAC |
| Production Efficiengcy | 150(Bottle/min) | 250(Bottle/min) |
| Size of Host Machine | L2100mm x W850mm x H2000mm | L2100mm x W850mm x H2000mm |
| Applicable Diameter of Bottle Body | D28mm-125mm | D28mm-125mm |
| Applicable Length of Lable | 30mm-250mm | 30mm-250mm |
| Applicable Thickness of Label | 0.03mm-0.13mm | 0.03mm-0.13mm |
| Applicable Internal Diameter of Paper Tube | (Free Adjustment) | (Free Adjustment) |
Zhangjiagang Huasheng Beverage Machinery Co., Ltd. was established in 1992, we are a private enterprise, specializing in liquid food and beverage filling and packaging machinery development, manufacturing and sales.
In the past 20 years, we are committed to the domestic market sales and service, we mainly serve small and medium-scale factories, (2000-20000 bottles per hour production line)
We have 300+ users in China, including some well-known brand, the users grow with us, they are not only our business partners but strong supporter of our further developping .From 2009, we began international sales and service, we hope to cooperate with more foreign companies in the future, we believe that the past 20 years of experience will enable us to do better, we are ready.
