Cheap Audio Real Time Recording 9ch 1080P P2p Onvif Poe Nvr for ip Camera Nvr System

Shenzhen CCDCAM Technology Co., Limited
Cheap Audio Real Time Recording 9ch 1080P P2p Onvif Poe Nvr for ip Camera Nvr System thumbnail-1
Cheap Audio Real Time Recording 9ch 1080P P2p Onvif Poe Nvr for ip Camera Nvr System thumbnail-2
Cheap Audio Real Time Recording 9ch 1080P P2p Onvif Poe Nvr for ip Camera Nvr System thumbnail-3
Cheap Audio Real Time Recording 9ch 1080P P2p Onvif Poe Nvr for ip Camera Nvr System photo-1
Cheap Audio Real Time Recording 9ch 1080P P2p Onvif Poe Nvr for ip Camera Nvr System photo-2
Cheap Audio Real Time Recording 9ch 1080P P2p Onvif Poe Nvr for ip Camera Nvr System photo-3
US$ 95 - 98 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
CCDCAM
Model Number:
NVR7109-POE
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/ Hongkong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name CCDCAM
Model Number NVR7109-POE

cheap audio real time recording 9ch 1080P p2p onvif poe nvr for ip camera nvr system



Features
Feature

Ø With H.264 High efficiency Video Compression
Ø With unique time screen in front of the panel, and displays recorder.
Ø Support Iphone, Android
Ø Support  2*USB2.0 for backup, burning, upgrading operation
Ø Support IE browse and CMS software Stronger network service.
Ø Support Chinese, English, Italian, Portuguese, Spanish, French, German ..... 18 languages
Ø With HDMI, Support 1080P high-definition (1920 * 1080P)
Ø With ONVIF protocol, can connect the ONVIF IP camera directly, also can by IE and CMS.
Ø Support P2P, cloud functions, POE



Specifiaction
Specification

 cheap audio real time recording 9ch 1080P p2p onvif poe nvr for ip camera nvr systemcheap audio real time recording 9ch 1080P p2p onvif poe nvr for ip camera nvr system



ModelNVR7109-POE
SystemMain ProcessorHigh performance embedded microprocessor
Operating systemEmbedded LINUX OS
Video spec.Video compression formatH.264
Display Image Resolution720P@30fps;960P@30fps;1080P@30fps
Playback Image Resolution720P@30fps;960P@30fps;1080P@30fps
Motion Detectioncan setup 192(16×12)pcs motion detection area eachchanneland
multi-level sensitivity(1-6 levels adjustable)
Privacy Maskingdepends on ipc
Audio spec.Audio compression formatG.711
two-way audio support
RecordingRecording ModeManual Recording, Motion Detection Recording, Time Recording,
Alarm Recording,
Recording storage HDD,Network
Frame rate30 fps NTSC;25fps PAL
Encode abilityRecording 9ch 1080P/720P@Playback 2ch 1080P/4ch 720P;
Backup ModeSupport HDD,USB Flash Disk store & backup
VideoNetwork Video Input9ch
Video output1ch VGA and 1ch HDMI
Audio Audio Input1ch by RCA (9ch by Network)
Audio Output1ch
OtherNetwork9x10/100Mbps,RJ45 port(8 port support POE)
POE8*POE (MAX 15.4W each / IEEE802.3AF)
USB 2 USB 2.0 ports
HDDsupport 2pcs 4TB SATA HDD inside
PowerDC +12V     (DC +48V for POE)
power consumption16W-18W(not include HDD and PoE)
Operation temperature0℃-+55℃
Operation humidity10%-90%
Demension335MM*252MM*50mm(1U height)
Weight 2.2KG(not include HDD)





packing
Packing

cheap audio real time recording 9ch 1080P p2p onvif poe nvr for ip camera nvr system

Company Information
Company information

Our advantages:

1.  Real  manufacurer

2. No MOQ ,small order is acceptable.

3. high quality with factory price

4. products with 1 years warranty

5. Profession aftersale service and technicist support

6. Fast delivery, DHL, UPS, Fedex are used

cheap audio real time recording 9ch 1080P p2p onvif poe nvr for ip camera nvr system
