Specifications
IP65.WF1, WF2.
10A.
FXM(D)- Water proof dust proof corrosion proof illumination(power) distribution box
1. Can be used in hazardous areas: Zone 1 and Zone 2 .
2. Can be used in explosive gas atmospheres of Category II B and II C where the temperature classification is T1-T6.
3. Hazardous zone : 20. 21. and 22
4. Flammable dust atmosphere.
5. widely using in the fields of oil, chemical industry , spaceflight ,war industry and so on.
Voltage |
Main circuit RATED CURRENT |
INLET thread |
Enclosure material |
Using type |
Degree of protection |
Erosionproofclass |
cableouterline (mm) |
AC220V/380V |
≤630A |
G1/2"-G3" |
GRP,aluminum alloy, Stainless steel |
AC-14 |
IP65 |
WF1,WF2
|
Φ9mm-Φ28mm |
APPlications:
- Ambient temperature:-25℃~55℃.
- Altitude:≤2000m.
- Can withstand the corrosion of acid, alkali, salt, ammonia, chlorine. They apply to washy, dusty and humidity environment.
- Widely used in the lines of peroleum, chemistry, dock, food, medicine, warindustry and so on.
- Various programs can be chosen, special requirements are available.
- Application for distribution of illumination or power system.
Techinical parameters:
- Rated voltage: AC220/380V
- Main circuit Rated current: ≤630A
- Nos of branches: Unlimited
- Branches rated current: ≤100A
- Protection grade: IP65
- corrosion-proof grade:WF1, WF2
- Inlet thread: G1/2"~G3"
- Cable outer dia:Φ6mm~Φ55mm
Product Features:
- Engineering plastic Glas reinforced polyester enclosure, with the elegant shape, corrosion resistance, static, electricity, resistance, impact resistance and good thermal reliability.
- Stainless steel enclosure is swelded by sheet steel, has elegant shape performance.
- Aluminum alloy enclosure is die casted of aluminum alloy, with high voltage powder electrostatic plastic-sprayed surface.
- L series production can resis the acid, salt and alkli, and its corrosion-proof grade is WF1.
- G and S series have greater function of resisting the acid, salt and alkli, and its corrosion-proof grade is WF2.
- L and S series are of labyrinth type, G series is of curve sealed structure. Both of them assure the high water-proof and dust-proof.
- Exposed fasteners of stainless steel material, and the sealing elements are made of silica, with good oil, acid, alkali-resistance and anti-aging.
- Equipped inside high breaking capacity MCBs or MCCBs, that makes on-off operation easily by opening up waterproof window on the casing cover.
- With overload, short circuit protection, and customized for each leakage protection at user's request.
- Suitable for application of power distribution or on-off control in illumination or power circuit, or a combination of illumination, power distribution and on-off control.
- Suitable for cable wiring. If need steel pipe wiring plz note.
