Specifications
LC Fiber Optic PigtailLow IL and High RL
High precision alignment
Various fiber optic pigtails with good price
ROHS
LC Fiber Optic Pigtail Characteristics:
- Compact, pull-proof design, with RJ-45 style interface
- Fully compatible with standard LC products
- Optional anti-snag simplex collar and duplex clip
- Pigtail body can be used for both simplex and duplex configurations
- Average insertion loss: 0.06 dB
- Average return loss: 55 dB
- Plastic housing and boot made from UL-rated materials
LC Fiber Optic Pigtail Application:
- Telecom / Datacom, LANs, CATV
- Fiber to the Home, Premises Distribution
- Gigabit Applications (Ethernet, ATM, SONET, etc.)
LC Fiber Optic Pigtail Brief Introduction
LC Fiber Optic Pigtail are small form factor fiber optic Pigtail. The LC Fiber Optic Pigtail resemble a small LC fiber Pigtails. Lucent Technologies first developed the LC Pigtail for TelCo environment uses. Hence, LC stands for Lucent Pigtails.LC fiber Pigtails have been standardized as FOCIS 10 (Fiber Optic Pigtail Intermateability Standards) in EIA/TIA-604-10. The LC Fiber Optic Pigtail uses a 1.25 mm ferrule, half the dimension of the ST ferrule or a regular ceramic ferrule Pigtail. The LC gives excellent performance and is greatly preferred for single mode transmission.
The TELEWEAVER LC Unibody is fully compatible with the original LC family of single-mode and multimode Pigtails, adapters and associated components, manufactured under a worldwide license from OFS Fitel. The Unibody features a compact, pull-proof design with RJ-45 style interface, and features a one-piece molded housing with internal strength member, for significantly improved 90º side-pull performance under Telcordia GR-326-CORE testing. It is manufactured using a ruggedized material that results in a latch trigger up to four times stronger than average.
The LC Unibody Series includes an optional anti-snag collar that prevents accidental tear and damage in high density networks. The collar comes in either simplex or duplex configurations, and can be used on the same Pigtail body, eliminating the need to purchase different housing styles. The series includes a jumper Pigtail designed for 2.0mm cordage, and a Behind the Wall (BTW) version for 900µm buffered fiber. The Unibody can be used for single-mode and multimode applications with either a PC or APC end-face. Plastic housing and boot made from UL rated materials are also available. The series is compliant with Telcordia GR-326-CORE, IEC 61754-20, and TIA/EIA 604-10 standards, and meets independent testing criteria from OFS Fitel.
LC Fiber Optic Pigtail Pictures:
-
LC Fiber Optic Pigtail
LC Fiber Optic Pigtail Paramters:
|
Type Parameters |
Single-mode |
Multimode |
||
Pigtail Type |
LC Fiber Optic Pigtail |
|||
Polishing Type |
PC |
UPC |
APC |
PC |
Insertion Loss (dB) |
≤0.2 |
≤0.25 |
||
Return Loss (dB) |
≥45 |
≥50 |
≥60 |
N/A |
Repeatability (dB) |
IL≤0.2 RL≤5 |
IL≤0.1 |
||
Vibration (dB) |
IL≤0.2 dB RL≤5dB |
IL≤0.2 dB |
||
Exchangeability (dB) |
IL≤0.2 dB RL≤5dB |
IL≤0.2 dB |
||
Tensile Strength |
F200N |
|||
Durability |
n=1000 |
|||
Operation Temperature (°C) |
-40°C~+80°C |
|||
Ferrule Material |
Zirconia Ceramic |
|||
Cable Diameter (mm) |
Ø0.9, Ø2.0, Ø3.0 |
|||
