Specifications
Fiber Optic Splice ClosureEasy to install
Different capacity
Aerial,wall-mounting,direct-bury
ISO9001,ISO14001,TL,RoHS
TWFOSCH-A Fiber Optic Splice Closure Characteristics:
- Holds up to 96 fibers and easy to re-enter Cable entry/exit ports
- Pressure testing valve and earth deriving device
- Integrated seal, air tight and water proof
- Ideal for cable repair and RoHS compliant
TWFOSCH-A Fiber Optic Splice Closure Application:
- Duct
- Aerial
- Direct buried
TWFOSCH-A Fiber Optic Splice Closure Brief Introduction
This fiber optic splice closure is easy to install for different applications. its capacity is from 12 cores to 48 cores. A larger dimension fiber optic splice closure is from 12 cores to 96 cores.
TWFOSCH-A Fiber Optic Splice Closure Pictures:
-
TWFOSCH-A Fiber Optic Splice Closure
TWFOSCH-A Fiber Optic Splice Closure Paramters:
Outside dimension (LxWxH) |
485x165x110 (mm) |
Weight (excluding outside box) |
2500g-2625g |
Number of inlet/outlet ports |
2 (pieces) on each side (total 4 pieces) |
Diameter of fiber cable |
Φ10—Φ22 (mm) |
Capacity of FOSC |
Bunchy: 12—96 (Cores) |
No. |
Components |
Quantity |
Usage |
Remark |
1 |
Housing |
1 set |
Protecting fiber cable splices in whole |
Internal diameter: 320x120x100(mm) |
2 |
FOST |
max. 6 pcs (bunchy) max. 4pcs (ribbon) |
Fixing heat shrinkable protective sleeve and holding fibers |
Suitable for: Bunchy:12,24(cores) Ribbon:3 (pieces) |
3 |
Foundation |
1 set |
Fixing reinforced core of fiber- cable and FOST |
|
4 |
Seal fitting |
1 set |
Sealing between FOSC cover and FOSC bottom |
|
5 |
Port plug |
6 pieces |
Sealing empty ports |
|
6 |
Pressure testing valve |
1 set |
After injecting air, it is used for pressure testing and sealing testing |
Configuration as per requirement |
7 |
Earthing deriving device |
1 set |
Deriving metallic components of fiber cable in FOSC for earthing connection |
Configuration as per requirement |
No. |
Accessories |
Quantity |
Usage |
Remarks |
1 |
Heat shrinkable protective sleeve |
Protecting fiber splices |
Configuration as per capacity |
|
2 |
Nylon tie |
Fixing fiber with protective coat |
Configuration as per capacity |
|
3 |
Insulation tape |
1 roll |
Enlarging diameter of fiber cable for easy fixing |
|
4 |
Seal tape |
1 roll |
Enlarging diameter of fiber cable which fits in with seal fitting |
Configuration as per specification |
5 |
Hanging hook |
1 set |
For aerial use |
|
6 |
Earthing wire |
1 piece |
Putting through between earthing devices |
|
7 |
Abrasive cloth |
1 piece |
Scratching fiber cable |
|
8 |
Labeling paper |
1 piece |
Labeling fiber |
|
9 |
Special wrench |
3 pieces |
Fixing bolts, tightening nut of reinforced core |
|
10 |
Measuring paper |
1 piece |
To measure circle, of which its diameter is enlarged with seal tape |
|
11 |
Buffer tube |
to be decided by customers |
Hitched to fibers and fixed with FOST, managing buffer |
Configuration as per requirement |
12 |
Desiccant |
1 bag |
Put into FOSC before sealing for desiccating air. |
