Specifications
SC Patch CordLow IL and High RL
High precision alignment
Various fiber optic patch cords with good price
ROHS
SC Patch Cord Features:
- Compliance with Telcordia, ANSI, IEC, TIA/EIA, NTT and JIS specifications
- Low insertion loss & back reflection
- One-piece construction & pull-proof design
- Free-floating ceramic ferrule
- Precision anti-rotation key and corrosion resistant body
- UL-rated plastic housing and boots in a variety of colors
- Telcordia style boots
- Adapters with choice of metal or plastic housing, mount styles & flange options
SC Patch Cord Applications:
- Optical Fiber Communications, Video, LAN, CATV Systemss
- Optical Network Equipments, Optical Test Equipmentss
- Module Pigtails, Multi-media, Premises
- Active device termination installationss
SC Patch Cord Brief Introduction:
SC Fiber Optic Connector is a snap-in connector fiber also with a 2.5 mm ferrule that is widely used for it Is excellent performance. It was the connector standardized in TIA-568-A, but was not widely used at first because it was twice as expensive as a ST. Now it's only a bit more expensive and much more common It Is a snap-in connector that latches with a simple push-pull motion. It is also available in a duplex configuration. SC Patch Cord is very popular in sc fiber patch cable and sc fiber pigtail making.
The Subscription Channel (SC) Connector is known for its locking mechanism which gives an audible click when pushed in or pulled out. This push-pull design prevents rotational misalignment. The SC/PC connector incorporates a Physical Contact (PC) curved polished ferrule end face that greatly reduces back-reflection over a ferrule with flat end-face.
The TELEWEAVER SC/PC connector is available in both single-mode and multimode versions, and is fully compatible with NTT-SC hardware. Both single-mode and multimode versions come with a zirconia ceramic ferrule with pre-polished PC profile and convex spherical end. This allows for fast polishing of the fiber and enables the installer to achieve low optical loss. while ensuring maximum repeatability.
The body is precision molded. Housing and boot are made from UL-rated material. Angled Physical Contact (APC) version is also available for ultra-low back-reflection. TELEWEAVER offers an SC Tunable Connector which allows four-position tuning for applications requiring precise fiber alignment.
SC Patch Cord Pictures:
-
SC Patch Cord
SC Patch Cord Paramters:
|
Type Parameters |
Single-mode |
Multimode |
||
Connector Type |
SC Patch Cord |
|||
Polishing Type |
PC |
UPC |
APC |
PC |
Insertion Loss (dB) |
≤0.2 |
≤0.25 |
||
Return Loss (dB) |
≥45 |
≥50 |
≥60 |
N/A |
Repeatability (dB) |
IL≤0.2 RL≤5 |
IL≤0.1 |
||
Vibration (dB) |
IL≤0.2 dB RL≤5dB |
IL≤0.2 dB |
||
Exchangeability (dB) |
IL≤0.2 dB RL≤5dB |
IL≤0.2 dB |
||
Tensile Strength |
F200N |
|||
Durability |
n=1000 |
|||
Operation Temperature (°C) |
-40°C~+80°C |
|||
Ferrule Material |
Zirconia Ceramic |
|||
Cable Diameter (mm) |
Ø0.9, Ø2.0, Ø3.0 |
|||
