Specifications
Fiber Optic fc/lc fiber optic patch cordLow IL and High RL
High precision alignment
Various fiber optic patch cords
FC-APC Fiber Optic Patch Cord Characteristics:
- Compliance with Telcordia, ANSI, IEC,TIA/EIA
- NTT and JIS specifications
- Low insertion loss & back reflection
- One-piece construction & pull-proof design
- Free-floating ceramic ferrule
- Precision anti-rotation key
- UL-rated plastic housing and boots in
- A variety of colors
- Telcordia style boots
- Corrosion resistant body (Nickel Plated Brass)
FC-APC Fiber Optic Patch Cord Application:
- Optical Fiber Communications, Video, LAN, CATV Systems
- Optical Network Equipments, Optical Test Equipments
- Optical Network Equipments,optical Test Equipments
- Module Pigtails, Multi-media, Premise
- Active device termination installations
FC-APC Fiber Optic Patch Cord Brief Introduction
FC-APC Fiber Optic Patch Cord was one of the most popular single-mode Pigtails for many years. It also uses a 2.5 mm ferrule, but some of the early ones use ceramic inside stainless steel ferrules. It screws on firmly, but you must make sure you have the key aligned in the slot properly before tightening. It's been mostly replaced by SCs and LCs. However, as a result of this characteristics for easy assemblies and installation, Our FC Fiber Optic Pigtails are every competitive.
The FC-APC Fiber Optic Patch Cord incorporates a Physical Contact (PC) curved polished fiber end face that greatly reduces back-reflection over the regular FC Patch Cord with flat end-face ferrule.
The TELEWEAVER FC-APC Fiber Optic Patch Cord is available in both single-mode and multimode versions, and is fully inter-mateable with NTT-FC products. Both single-mode and multimode versions come with a zirconia ceramic ferrule with pre-polished PC profile and convex spherical end. These end-face types allow for faster polishing, and low back reflection and optical loss, while ensuring maximum repeatability.
TELEWEAVER offers an FC Tunable Patch Cord with four-position tuning for applications requiring precise fiber alignment. A specially designed FC PM Patch Cord is available for use with Polarization Maintaining Fiber.
FC-APC Fiber Optic Patch Cord Pictures:
-
FC-APC Fiber Optic Patch Cord
FC-APC Fiber Optic Patch Cord Paramters:
|
Type Parameters |
Single-mode |
Multimode |
||
Patch Cord Type |
FC Fiber Optic Patch Cord |
|||
Polishing Type |
PC |
UPC |
APC |
PC |
Insertion Loss (dB) |
≤0.2 |
≤0.25 |
||
Return Loss (dB) |
≥45 |
≥50 |
≥60 |
N/A |
Repeatability (dB) |
IL≤0.2 RL≤5 |
IL≤0.1 |
||
Vibration (dB) |
IL≤0.2 dB RL≤5dB |
IL≤0.2 dB |
||
Exchangeability (dB) |
IL≤0.2 dB RL≤5dB |
IL≤0.2 dB |
||
Tensile Strength |
F200N |
|||
Durability |
n=1000 |
|||
Operation Temperature (°C) |
-40°C~+80°C |
|||
Ferrule Material |
Zirconia Ceramic |
|||
Cable Diameter (mm) |
Ø0.9, Ø2.0, Ø3.0 |
|||
