Help CenterFiber Optic sc 2.0mm Connector China Manufacturer
Related Products
fiber optic sc connector Features:
- Good durability and exchangability
- Various Connector Type Available
- High temperature stability
- Low Insertion Loss and Back Reflect
fiber optic sc connector Applications:
- Optical Fiber Communications
- Video,LAN, CATV Systems
- Optical Network Equipments,optical Test Equipments
- Module Pigtails,Multi media,Premise
- Active device termination installations
fiber optic sc connector Brief Introduction:
SC connector fiber is a snap-in connector fiber also with a 2.5 mm ferrule that is widely used for it's excellent performance. It was the connector standardized in TIA-568-A, but was not widely used at first because it was twice as expensive as a ST. Now it's only a bit more expensive and much more common It's a snap-in connector that latches with a simple push-pull motion.It is also available in a duplex configuration. SC connector is very popular in sc fiber patch cable and sc fiber pigtail making.
fiber optic sc connector Pictures:
fiber optic sc connector
fiber optic sc connector Paramters:
|
Type Parameters |
Single-mode |
Multimode |
||
Connector Type |
SC Fiber Optic Connector |
|||
Polishing Type |
PC |
UPC |
APC |
PC |
Insertion Loss (dB) |
≤0.2 |
≤0.25 |
||
Return Loss (dB) |
≥45 |
≥50 |
≥60 |
N/A |
Repeatability (dB) |
IL≤0.2 RL≤5 |
IL≤0.1 |
||
Vibration (dB) |
IL≤0.2 dB RL≤5dB |
IL≤0.2 dB |
||
Exchangeability (dB) |
IL≤0.2 dB RL≤5dB |
IL≤0.2 dB |
||
Tensile Strength |
F200N |
|||
Durability |
n=1000 |
|||
Operation Temperature (°C) |
-40°C ~+80°C |
|||
Ferrule Material |
Zirconia Ceramic |
|||
Cable Diameter (mm) |
Ø0.9, Ø2.0, Ø3.0 |
|||
Other Fiber Optic Connectors:
-
SC Fiber Optic Connector
-
FC Fiber Optic Connector
-
LC Fiber Optic Connector
-
ST Fiber Optic Connector
-
MU Fiber Optic Connector
-
E2000 Fiber Optic Connector
-
MTRJ Fiber Optic Connector
-
SMA Fiber Optic Connector
-
D4 Fiber Optic Connector
-
DIN Fiber Optic Connector
-
MPO Fiber Optic Connector
