Help CenterMPO Fiber Optic Cable Connector
Related Products
Specifications
MPO fiber optic cable connector1.ROHS Compliant
2.Low IL & High RL
3.High precision alignment
4.MPO connector SM & MM
MPO fiber optic cable connector Characteristics:
- Patented floating ferrule design ensures fiber contact integrity
- Terminate ribbon fiber or loose individual fibers
- Low loss and standard loss SM and MM versions
- Patented elliptical guide pin tip to Minimise ferrule debris
- Ruggedised round cable, oval cable and bare ribbon options available
- Housing is removable for quick change of pin clamps and easy ferrule cleaning or re-polishing
- Alignment achieved with high precision guide pins
- Family of bulkhead adaptors available
MPO fiber optic cable connector Application:
- Optical Fiber Communications, Video, LAN, CATV Systems
- Optical Network Equipments, Optical Test Equipments
- Optical Network Equipments,optical Test Equipments
- Module Pigtails, Multi-media, Premise
- Active device termination installations
MPO fiber optic cable connector Brief Introduction
MTP/MPO fiber optic cable connector is a 12 Fiber Optic Connector for ribbon cable. This Fiber Optic Connectors main use is for pre-terminated cable assemblies and cabling systems. The MTP Fiber Optic Connector provides rapid connection of 12 fibers. The integrity of the connection is provided by latches within the adaptor which are secured into place on the Fiber Optic Connector with a spring loaded mechanism. Precision alignment is achieved with specially designed guide pins. MTP connectors have a unique removable housing which allows for a quick change of gender, ferrule cleaning, interferometric inspection or connector re-work
The single-mode or multimode MPO products available from TELEWEAVER are multi-fiber connections used in high-density backplane and Printed Circuit Board (PCB) applications in data and telecommunications systems. The MPO connector offers up to 12 times the density of standard connectors, providing significant space and cost savings.
MPO connectors utilize precision molded MT ferrules, with metal guide pins and precise housing dimensions to ensure fiber alignment when mating. The MPO can be mass terminated in combinations of 4, 8, or 12 fiber ribbon cables. The MPO Adapter comes standard in black.
MPO fiber optic cable connector Pictures:
-
MPO fiber optic cable connector
MPO fiber optic cable connector Paramters:
Parameters |
Elite Single-mode MT Ferrule |
Standard |
Elite Multimode MT Ferrule |
Standard Multimode MT Ferrule |
Single-mode MT Ferrule | ||||
Insertion Loss |
0.10dB Typical 0.35dB Max |
0.25dB Typical 0.75dB Max |
0.10dB Typical 0.35dB Max |
0.20dB Typical 0.6dB Max |
Return Loss |
>55dB (Angle Polish) |
>55dB (Angle Polish) |
>20dB |
>20dB |
Operational Temp |
- 40°C to + 70°C |
- 40°C to + 70°C |
- 40°C to + 70°C |
- 40°C to + 70°C |
Other Fiber Optic Connectors:
-
SC Fiber Optic Connector
-
FC Fiber Optic Connector
-
LC Fiber Optic Connector
-
ST Fiber Optic Connector
-
MU Fiber Optic Connector
-
E2000 Fiber Optic Connector
-
MTRJ Fiber Optic Connector
-
SMA Fiber Optic Connector
-
D4 Fiber Optic Connector
-
DIN Fiber Optic Connector
-
MPO Fiber Optic Connector
