Specifications
Single-mode Monolithic Steel Fused Fiber Optic SplitterLow IL and High RL
High precision
Fiber splitter of different ratio
Single-mode Monolithic Steel Fused Fiber Optic Splitter Characteristics:
- Different combinations of coupling ratio
- Low crosstalk & excess loss
- High optical return loss
- Available in dual/three wavelength operation
- Optional connector termination upon request
- Available in 250um & 900um fiber, 2mm or 3mm
Single-mode Monolithic Steel Fused Fiber Optic Splitter Application:
- FTTH, LAN, PON & Optical CATV
- Local ring net, Optical fiber communication system
- Optical fiber test equipment, Optical fiber sensor
Single-mode Monolithic Steel Fused Fiber Optic Splitter Brief Introduction
Fiber optic splitter, also called optical splitter, fiber optic coupler, is a device applied in optical fiber systems with one or more input fibers and one or several output fibers. There are mainly two types of optical splitters. One is fused splitter (FTB),The other is Planar Lightwave Circuits (PLC Splitter).For the fused optical splitter, It can be divided into different ratios. such as 50/50 if the split is even, or 80/20 if 80% of the signal goes to one side and only 20% to the other. Planar Lightwave Circuits (PLC Splitter) can not work with different ratio rather than it provide a accurate splitting in high-density output (like 8,16,32,64 outputs). However, The most common type of fiber optic splitter splits the output evenly, which is coming out with the same output of light signals. As a result of its great function, Optical splitter is a very important part in passive optic networks (PON).
Single-mode Monolithic Steel Fused Fiber Optic Splitter Pictures:
-
Single-mode Monolithic Steel Fused Fiber Optic Splitter
-
Single-mode Monolithic Steel Fused Fiber Optic Splitter
Single-mode Monolithic Steel Fused Fiber Optic Splitter Paramters:
Grade Parameter |
Grade A |
|||
Operation Wavelength (nm) |
1310 or 1550,1310/1550,1310/1490/1550 |
|||
Bandwidth (nm) |
±20nm/±40nm |
|||
Max.Excess Loss (dB) |
≤0.1dB(0.06dB TYP) |
|||
Coupling Ratio (%) |
50/50 |
40/60 |
30/70 |
20/80 |
Typ. Insertion Loss (dB) |
3.1 |
4.1/2.4 |
5.4/1.7 |
7.2/1.1 |
Max. Insertion Loss (dB) |
3.4 |
4.5/2.7 |
5.8/2.0 |
7.6/1.5 |
Polarization Dependent Loss (dB) |
0.1 |
0.1 |
0.15/0.1 |
0.15/0.1 |
Thermal Stability (dB /°C) |
≤0.2dB |
|||
Directivity (dB) |
≥55 dB(≥60dB 2×2) |
|||
Operating Temperature(°C) |
-40°Cto +85°C |
|||
Package Type |
1.bare fiber 2.0.9 loose tube nnector type: FC/APC,FC/PC,SC/APC,SC/PC, all is optional |
|||
Pigtail Length |
1 meter, others on request |
|||
Package Dimensions(mm) |
Ø3*46(min size) Ø3*54 |
|||
