Help Center1x4, 1 8 Fiber Optic Splitter Single-mode 19 Inches Rack Pluggable Fused Fiber Optic Splitter
Related Products
-
1x2 Single Mode Fiber Optic Splitter CouplerUS$ 4.4 - 24.2MOQ: 1 Piece -
1 4 Fiber Optic Splitter Single-mode 19 Inches Rack Pluggable Fused Fiber Optic SplitterUS$ 4.4 - 24.2MOQ: 1 Piece
-
Single-mode Module Type Fused Optic Fiber Splitter PriceUS$ 4.4 - 24.2MOQ: 1 Piece
-
Single-mode Module Type Fused Optical Fiber Splitter LossUS$ 4.4 - 24.2MOQ: 1 Piece
-
Filtered WDM 1310-1490-1550nmUS$ 6.4 - 28.2MOQ: 1 Piece
Specifications
Single-mode 19 inches Rack Pluggable Fused Fiber Optic SplitterLow IL and High RL
High precision
different ratios
Single-mode 19 inches Rack Pluggable Fused Fiber Optic Splitter Characteristics:
- Different combinations of coupling ratio
- Low crosstalk & excess loss 3 High optical return loss
- Available in dual wavelength operation
- Optional connectors termination upon request
- Available in 250um & 900um fiber, 2mm or 3mm jacket optical cable
- 5U 19″standard type
- Applicable to engine room while practical and beautiful
- Applicable for various kinds of optical coupler
Single-mode 19 inches Rack Pluggable Fused Fiber Optic Splitter Application:
- FTTH, LAN, PON & Optical CATV
- Local ring net, Optical fiber communication system
- Optical fiber test equipment, Optical fiber sensor
Single-mode 19 inches Rack Pluggable Fused Fiber Optic Splitter Brief Introduction
Fiber optic splitter, also called optical splitter, fiber optic coupler, is a device applied in optical fiber systems with one or more input fibers and one or several output fibers. There are mainly two types of optical splitters. One is fused splitter (FTB),The other is Planar Lightwave Circuits (PLC Splitter).For the fused optical splitter, It can be divided into different ratios. such as 50/50 if the split is even, or 80/20 if 80% of the signal goes to one side and only 20% to the other. Planar Lightwave Circuits (PLC Splitter) can not work with different ratio rather than it provide a accurate splitting in high-density output (like 8,16,32,64 outputs). However, The most common type of fiber optic splitter splits the output evenly, which is coming out with the same output of light signals. As a result of its great function, Optical splitter is a very important part in passive optic networks (PON).
Single-mode 19 inches Rack Pluggable Fused Fiber Optic Splitter Pictures:
-
Single-mode 19 inches Rack Pluggable Fused Fiber Optic Splitter
-
Single-mode 19 inches Rack Pluggable Fused Fiber Optic Splitter
Single-mode 19 inches Rack Pluggable Fused Fiber Optic Splitter Paramters:
Parameters |
Fiber Optic Splitter |
|||||
Center wavelength |
1310/1550nm or 1310nm&1550nm or 1310nm&1490nm&1550nm |
|||||
Bandwidth |
±20 or 40 nm |
|||||
Tree structure |
1x4 |
1x8 |
1x12 |
1x16 |
1x20 |
1x24 |
Insertion loss |
7.2 dB |
10.8 dB |
13.3 dB |
14.5 dB |
15.8 dB |
16.8 dB |
Uniformity |
1.5 dB |
2.0 dB |
2.3 dB |
2.5 dB |
2.8 dB |
2.8 dB |
Connector |
FC/APC or SC/APC, others for client specify |
|||||
Directivity |
>60 dB |
|||||
Operation temperature |
-20 ~ +75°C |
|||||
Storage temperature |
-40 ~ +85°C |
|||||
Dimension |
19inch, 1U |
|||||
Wavelength |
Package Size |
Ports |
Fiber Types |
Fiber |
Cable |
Connector |
13=1310nm |
FB=bare fiber |
102 |
0=G652D |
1=250um |
0=0m |
1=SC/APC |
14=1490nm |
ST=stainless |
103 |
1=G657A |
2=900mm |
1=1m |
2=SC/PC |
15=1550nm |
Steel tube |
104 |
C=customize |
3=2.0mm |
2=1.5m |
3=FC/APC |
35=1310nm |
PB=plastic |
105 |
4=3.0mm |
3=2.0m |
4=FC/PC |
|
&1550nm |
MB=Metal |
……. |
C=customize |
5=ST/APC |
||
345=1310&1490 |
196 |
6=ST/PC |
||||
&1550nm |
203 |
7=LC/APC |
||||
204 |
8=LC/PC |
|||||
205 |
9=Customize |
|||||
…… |
||||||
296 |
||||||
202 |
||||||
404 |
||||||
808 |
||||||
1616 |
