TWFOPM-B Fiber Optic Power MeterUser self-calibration function
Optional 10mins Auto-off
Low battery power indication
RoHS
TWFOPM-B Fiber Optic Power Meter Characteristics:
- Reference power level storage(Ref Setting)
- User self-calibration function
- Comfortable LCD display and backlight LCD display supports night operation.
- Power measurements in dBm or mw and insertion loss in dB
- Optional 10 minutes Auto-off function
- AA alkaline batteries can last more than 140 hours, AC adaptor also available
- Low battery power indication
TWFOPM-B Fiber Optic Power Meter Application:
- Maintenance in Telecom
- Maintenance CATV
- Test Lab of Optical Fibers
- Other Fiber Optic Measurements
TWFOPM-B Fiber Optic Power Meter Brief Introduction
It is a handheld optical power meter, newly released in 2007, which can be used for absolute optical power measurements as well as for relative loss measurements in optical fibers. A 2.0mm photosensitive area photodiode is used to significantly improve the stability and the reliability. It features ingenious appearance, a wide range of power measurement, high accuracy, an user self-calibration function and a reference power level storage.
TWFOPM-B Fiber Optic Power Meter Pictures:
-
TWFOPM-B Fiber Optic Power Meter
TWFOPM-B Fiber Optic Power Meter Paramters:
MODEL |
TWFOPM-B A |
TWFOPM-B C |
Wavelength(nm) |
800~1700nm |
|
Detector Type |
InGaAs |
|
Detector Size |
Ø 1.0mm |
Ø 1.0mm |
Measurement Range (dBm) |
-70~+10 |
|
Uncertainty |
±5% |
|
Calibrated Wavelength(nm) |
8.5013E+22 |
|
Resolution(dB) |
0.01 |
|
Optical Connector |
FC(interchangeable SC,ST) / as well as 2.5mm universal |
|
Power Supply |
Alkaline Battery(3 AA 1.5V batteries); AC Adapter (9V) |
|
Battery Operating Time |
140 h with 1.5VBattery(3pcs) |
|
Operating Temperature(°C) |
-10 ~ +60 |
|
Storage Temperature(°C) |
-25 ~ +70 |
|
Relative Humidity |
0 to 95% (non-condensing) |
|
Dimension(mm) |
190X100X50 |
|
Weight(g) |
370 |
|
