CHINA SUPPLIER WATER PROOF DUST PROOF CORROSION PROOF CONTROL BOX FXK
1. Can be used in hazardous areas: Zone 1 and Zone 2 .
2. Can be used in explosive gas atmospheres of Category II B and II C where the temperature classification is T1-T6.
3. Hazardous zone : 20. 21. and 22
4. Flammable dust atmosphere.
5. widely using in the fields of oil, chemical industry , spaceflight ,war industry and so on.
6.Engineering plastic Enclosure is made of glass reinforceed polyester,with good explosion proof .
7.L series production can resist the acid,salt and alkli,and its corrosion-proof grade is WF1.
8.G and S series have grater function of resisting the acid,salt and alkli,and its corrosion proof grade is WF2.
Voltage |
RATED CURRENT |
INLET thread |
Mounting mode |
Using type |
Degree of protection |
Erosionproofclass |
cableouterline (mm) |
AC220V/380V |
10A |
G3/4"-G11/2" |
G L |
AC-14 |
IP65 |
WF1,WF2
|
Φ9mm-Φ28mm |
APPlications:
- Ambient temperature:-25℃~55℃.
- Altitude:≤2000m.
- Can withstand the corrosion of acid, alkali, salt, ammonia, chlorine. They apply to washy, dusty and humidity environment.
- Widely used in the lines of peroleum, chemistry, dock, food, medicine, warindustry and so on.
- Be used in electrical control system to send orders and monitoring.
- Various programs can be chosen, special requirements are available.
Techinical parameters:
- Rated voltage: AC220/380V
- Rated current: 10A
- Using type: AC-14
- Protection grade: IP65
- corrosion-proof grade:WF1, WF2
- Inlet thread: G3/4"~G1/2"
- Cable outer dia:Φ9mm~Φ28mm
Product Features:
- Glas reinforced polyester enclosure, with the elegant shape, corrosion resistance, static, electricity, resistance, impact resistance and good thermal reliability.
- Stainless steel enclosure is swelded by sheet steel, has elegant shape performance.
- Aluminum alloy enclosure is die casted of aluminum alloy, with high voltage powder electrostatic plastic-sprayed surface.
- L series production can resis the acid, salt and alkli, and its corrosion-proof grade is WF1.
- G and S series have greater function of resisting the acid, salt and alkli, and its corrosion-proof grade is WF2.
- L and S series are of labyrinth type, G series is of curve sealed structure. Both of them assure the high water-proof and dust-proof.
- Exposed fasteners of stainless steel material
- It is adapted to the circuit with AC50Hz, whose voltage must be lower than 380V, and current must be lower 10A. It is used to control the start, stop, charger over of the motor, the change fo the signals, and show the result of the metering instrument.
- The control panel with indicators, buttons, universal swiftches, ammeter and voltmeter, etc. We can add other devices according to the users' requirement.
- The user can combine different parts arbitrarily.
- Universal switch with about 30 kinds of function for users to choose.
- Suitable for cable wiring. If need steel pipe wiring plz note.
