Specifications
- Equivalent to 20 reaping labors- Operating on dry field or flooded field
- Powder coated and Fiction clutch
- Compact
Rice reaper is agricultural machine used to cut the grain, the rice, wheat, pepper, the bean and other crops, suitable for the mountainous region.
SPECIFICATION
Model | NP-120 | |
Type | Paddy/rice reaper | |
Working capacity (m2/hour) | 3000 - 4000 | |
Fuel consumption (litter/hour) | 1.0 – 1.5 gasoline | |
Crop | Rice, wheat | |
Harvesting loss (%) | 1.0 – 1.2 | |
Harvesting field | Dry, wet, or 10cm-water flooded | |
Maximum angle of inclined crop plant (degree) | 60o | |
Reaping | Reaping width (cm) | 120 |
Reaping height (cm) | 3 – 50 | |
Reaping device | Reciprocating blade bar | |
Engine | Type | 4 cycle, air-cooled gasoline |
Power (hp@rpm) | 4.5 – 6.5 @ 3600 | |
Fuel | Gasoline | |
Travel speed (m/min) | Forward | 60 |
Reverse | 45 | |
Wheel (cm) | Cage wheel: 46 x 22 Option: lug tire wheel: 45 x 23 | |
Operation and Control | Main clutch | Dog clutch |
Harvesting clutch | Dog clutch | |
Height adjustment and handle (cm) | 75 - 90 | |
Delivery | Upper delivery device | Revolving chain with lug plates |
Lower delivery device | Revolving chain | |
Crop plant release | Right side (viewed from rear of machine) | |
Dimension | L x W x H (cm) | 200 x 135 x 110 |
Weight (without engine) (kg) | 135 | |
BLADES
RUBBER WHEEL
CAGE IRON WHEEL
READY TO SHIP
PACKAGING
COMPLETE SET
OUR FACTORY
OUR WARE HOUSE
LOADING IN CONTAINER
VIDEO DEMONSTRATION
http://youtu.be/h2pAd_c0Q88
CONTACT US
