Out of ordinary price 2NO 25A manually-operated Household mini Contactor
Application
CT modular contactor is applicable to alternative circuit with rated voltage up to 400V, rated current up to 100A and rated frequency 50/60Hz. The product is used for remote switching and controlling of power circuit.
Product Description
CT contactors are available in two versions:
Contactors without manually-operated
Contactors with manually-operated
The breadth of the CT contactor range satisfies most application cases.
CT contactors can be combined with auxiliary control, protection and indication functions.
Normal operation and mounting requirement
1.Circumstance temperature -5°C ~ +40°C, average temperature within 24h not exceeding +35°C.
2.Altitude above sea level less than 2000 m.
3.Humidity not exceeding 50% at 40°C and not exceeding 90% at 25°C.
4.Installation class II or III.
5.Pollution class 2.
6.Installation method DIN Rail mounting type.
7.The external magnetism shall not be more than 5 times of terrestrial one.
8.Product shall be installed at the place where there shall be no severe impact and vibration.
Company profile
Located in the state-level high -tech pioneering pack in Shanxi Province, Assimy is a company which designs and produces high and low voltage electrical equipments and accessories. In order to expand business scope, Assimy set up a branch company in Liushi Wenzhou.
Assimy has a wide range of electric accessories include Magnetic contactor, Household contactor, CJ20, CJX2, GMC, Air conditioning contactor,DZ47-63,DZ47LE circuit breaker, Moulded case circuit breaker, Dual power automatic transfer switch, Isolating switch, Magnetic starter, Self loading type overvoltage and under voltage protection device, Power supply of the switch, Fuse, Surge protective device, etc.
