Telemecanique Contactor Coil 16A 2P 240V 2NO Manual Operate Household Contactor
Application
CT modular contactor is applicable to alternative circuit with rated voltage up to 400V, rated current up to 100A and rated frequency 50/60Hz. The product is used for remote switching and controlling of power circuit.
| Rated Current (A) | 16,20, 25, 40,63,100 |
| Rated Voltage (V) | 230V 2P, 4P |
| 400V 4P | |
| Rated Frequency(Hz) | 50/60Hz |
| Electrical endurance | 30, 000 cycles |
| Mechanical endurance | 100, 000 cycles |
| Ambient temp. | pillar terminal with clamp |
| Installation | On symmetrical DIN Rail |
| Power circuit | |
| Voltage rating (Ue)2P | 230/240VAC/24V |
| Frequency | 50HZ or 60Hz |
| Electrical | 100,000 cycles |
| Maximum number of switching operation a day | 100 |
| Additional characteristics | |
| Insulation voltage Ui | 500VAC |
| Pollution degree | 2 |
| Rated impulse withstand voltage (Uimp) | 2.5kv(4kv for 12/24/48VAC ) |
| Degree of protection device only | IP20 |
| IEC60529 Device in modular enclosure | IP40 |
| Operating temperature | -5 to 60 degree |
| Storage temperature | -40~70degree |
| Tropicalization (IEC60068-1) | Treatment 2 (relative humidity 95% at 55 degree ) |
| ELSV compliance (extra low safety voltage )for 12/24/48vac versions | |
| The products control confirms to the selv(safety extra low voltage )requirements | |
Payment term
1. 30% T/T advance , the balance against to the copy B/Lor LC at sight
3. Pls confirm the details with us before do the prepayment.
Product Display
Company profile
Located in the state-level high -tech pioneering pack in Shanxi Province, Assimy is a company which designs and produces high and low voltage electrical equipments and accessories. In order to expand business scope, Assimy set up a branch company in Liushi Wenzhou.
Assimy has a wide range of electric accessories include Magnetic contactor, Household contactor, CJ20, CJX2, GMC, Air conditioning contactor,DZ47-63,DZ47LE circuit breaker, Moulded case circuit breaker, Dual power automatic transfer switch, Isolating switch, Magnetic starter, Self loading type overvoltage and under voltage protection device, Power supply of the switch, Fuse, Surge protective device, etc.
PS: If you can't find the exact type of your product.Please don't rush to go away.Contact me and your questions will be replied ASAP.Thank you for your time.
