Home > Electrical & Electronics > Relay & Contactor > Contactor > Aissmy Household AC Contactor 1p 2p 3p 4p 250v 400v

Aissmy Household AC Contactor 1p 2p 3p 4p 250v 400v

Name: Aissmy Household AC Contactor 1p 2p 3p 4p 250v 400v
Brand: Aissmy
SKU: 119759063

Aissmy Household AC Contactor 1p 2p 3p 4p 250v 400v thumbnail-1

Aissmy Household AC Contactor 1p 2p 3p 4p 250v 400v thumbnail-2

Aissmy Household AC Contactor 1p 2p 3p 4p 250v 400v thumbnail-3

Aissmy Household AC Contactor 1p 2p 3p 4p 250v 400v thumbnail-4

Aissmy Household AC Contactor 1p 2p 3p 4p 250v 400v thumbnail-5

Aissmy Household AC Contactor 1p 2p 3p 4p 250v 400v photo-1

Aissmy Household AC Contactor 1p 2p 3p 4p 250v 400v photo-2

Aissmy Household AC Contactor 1p 2p 3p 4p 250v 400v photo-3

Aissmy Household AC Contactor 1p 2p 3p 4p 250v 400v photo-4

Aissmy Household AC Contactor 1p 2p 3p 4p 250v 400v photo-5

US$ 0.5 - 60 MOQ: 10 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

Aissmy

Model Number:

ct-16a

Contact Supplier Request Quote Chat Now

Shanxi Aisiman Electric Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai or ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name Aissmy

Model Number ct-16a

Electricity Type AC

Number of Pole Other, 1\2\3\4

Phase Other, 1\2\3\4

Main Circuit Rating Voltage Other, 250v 400v

Main Circuit Rating Current Other, 16a 6a

Household ACcontactor

The contactor is mainly used in the power system of AC 50HZz/60Hz,rated voltage up to 400v,rated working current up to 100A,under the AC-1,AC-7a using categories,for long distance switch and control circuit.

Main technical parameters

Model			16A	20A	25A	40A	63A	100A
In(A) Rated current In(A)	AC-7a		16	20	25	40	63	100
	AC-7b		6	7	8.5	15	20	30
Prescribed heating current Ith(A)			25	25	25	63	63	100
Rated insulation voltage Ui(V)			500
Rated operating voltage Ue(V)			250V(1P 2P) 400V(3P 4P)
Number of main contacts	1P		1NO 1NC
	2P		1NO1NC 2NO2NC
	3P		3NO 3NC
	4P		2NO2NC 3NO1NC 4NO 4NC
Control power (KW)	AC-7a	230V	3.5	4.5	5.5	9	14	22
		400V	6.5	8	10	16	25	38
	AC-7b	230V	1.4	1.6	2	3.5	4.5	5.5
		400V	2.4	2.4	3.4	6	8	11
Electrical life (times)			10*10000
Mechanical life (times)			100*10000
Maximum switching frequency/1h			30
Rated control supply voltage Us (V)			AC 24/50Hz AC 230/50Hz

Product display

Company Profile:

Located in the state-level high -tech pioneering pack in Shanxi Province, Assimy is a company which designs and produces high and low voltage electrical equipments and accessories. In order to expand business scope, Assimy set up a branch company in Liushi Wenzhou.

Assimy has a wide range of electric accessories include Magnetic contactor, Household contactor, CJ20, CJX2, GMC, Air conditioning contactor,DZ47-63,DZ47LE circuit breaker, Moulded case circuit breaker, Dual power automatic transfer switch, Isolating switch, Magnetic starter, Self loading type overvoltage and under voltage protection device, Power supply of the switch, Fuse, Surge protective device, etc.
