Peanut Combine Harvester DC-35

Name: Peanut Combine Harvester DC-35
Brand: KUBOTA
SKU: 119758729
Availability: InStock

Negotiable MOQ: 3 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Combine Harvester

Drive Type:

Gear Drive

Viet Nam Made Co., Ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

HO CHI MINH VIET NAM

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Combine Harvester

Drive Type Gear Drive

Usage Grain Harvester

Place of Origin Japan

Brand Name KUBOTA

Model Number DC-35

Dimension(L*W*H) 4120 x 1850 x 2150

Weight 1550 kg

After-sales Service Provided No overseas service provided

Product Description

DC-35 SPECIFICATIONS
Model			DC-35
Dimensions	Overall length ( mm )		4120
	Overall width ( mm )		1850
	Overall Height [with canopy stored] ( mm )		2150
Weight ( kg )			1550
Engine	Model		Kubota D1105 T-E2-C-1
	Type		Water-cooled 4-Cycle 4-Cylinder Turbocharged Vertical Diesel
	Displacement ( litre )		2.434
	Output (kW(PS)/rpm)		24.5 (33.3) - 3000
	Fuel Tank Capacity ( litre )		60
Drive System	Crawlers
		Width x Ground Contact Length	400 x 1330
		(mm)
		Average Ground Contact	14.3 (0.15)
		Pressure (kgf/cm2)
		Minimum Ground Clearance	300
		(mm)
	Transmission	Type	HST 3-Range (3F/3R)
		Traveling Speed (m/s) F/R	Low: 0-0.70

			High: 0-1.10
	Steering		Clutch and Brake
Cutting	Pickup Reel Diameter x Width ( mm(inch) )		800 x 1420
	Height Adjustment		Hydraulics
	Gathering length ( mm(inch) )		1600
	Cutter Bar length ( mm(inch) )		1448

Threshing /	Threshing System		Spiked Tooth Axial Flow
Separating	Threshing	Diameter x Length (mm)	545 x 1520
	Cylinder	Revolutions (rpm)	630
		Concave Area (m2)	0.991
Cleaning			Oscillating • 3 Way Air Stream Cleaning System
Grain Tank	Capacity ( kg/l )		130
Electrical System			12 Volts Battery Starting, Lighting equipment, Alarms
			Electrical System (Coolant Temperature, Battery Charge,
			Engine Oil, Grain Tank Full, and Tailings Clogging)
Harvesting Capacity* (ha/hr)			0.1 – 0.3 for Rice
