Home > Industrial Equipment & Components > Compressor > Compressor Unit > 10Bar 90KW Rotary Screw Air Compressors for Painting
10Bar 90KW Rotary Screw Air Compressors for Painting
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Screw
Configuration:
Stationary
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Low db Portable Air Compressor for MiningUS$ 10,415 - 13,694MOQ: 1 Unit -
Portable Compressor Air Screw With Specialized MountNegotiableMOQ: 1 Unit
-
2014 China ac Air Compressor for Industrial ApplicationNegotiableMOQ: 1 Unit
-
Portable AC Lubricant Oil Air Compressor for Spray PaintingNegotiableMOQ: 1 Unit
-
Cabinet Configuration Gas Air Compressor ManufactureNegotiableMOQ: 1 Unit
Condition
New
Type
Screw
Configuration
Stationary
Power Source
AC Power
Lubrication Style
Lubricated
Mute
Yes
Place of Origin
Fujian, China
Brand Name
JULUX AIR
Model Number
JLS-7.5F
Voltage
220V/380V/415V(customizable)
Dimension(L*W*H)
750x730x840 mm
Weight
220KG
Certification
ISO9001-2008
After-sales Service Provided
No overseas service provided
10Bar 90KW rotary screw air compressors for painting
Technical Parameters:
Part 1
| Air compressor model | JLS-7.5F | JLS-11F | JLS -15F | JLS-18.5F | JLS-22 F/S | JLS-30 F/S | JLS-37 F/S | JLS-45 F/S | JLS-55 F/S | JLS-75 F/S | ||||
|
Free Air Delivery (m3/min) (Mpa) |
1.4/0.7 | 2.03/0.7 | 2.6/0.7 | 3.2/0.7 | 3.95/0.7 | 5.25/0.7 | 6.82/0.7 | 8.03/0.7 | 10.8/0.7 | 14.1/0.7 | ||||
| 1.3/0.8 | 1.81/0.8 | 2.4/0.8 | 2.92/0.8 | 3.8/0.8 | 5.06/0.8 | 6.46/0.8 | 7.61/0.8 | 10.2/0.8 | 13.3/0.8 | |||||
| 1.1/1.0 | 1.51/1.0 | 2.0/1.0 | 2.65/1.0 | 3.2/1.0 | 4.53/1.0 | 5.83/1.0 | 7.0/1.0 | 9.0/1.0 | 11.6/1.0 | |||||
| 1.0/1.25 | 1.2/1.25 | 1.7/1.25 | 2.1/1.25 | 2.8/1.25 | 3.9/1.25 | 5.06/1.25 | 6.1/1.25 | 8.4/1.25 | 10.0/1.25 | |||||
| Motor | Voltage/Frequency | V/Hz | 220V/ 380V/ 415V & 50HZ/ 60HZ | |||||||||||
| Power | KW/HP | 7.5/10 | 11./15 | 15/20 | 18.5/25 | 22/30 | 30/40 | 37/50 | 45/60 | 55/75 | 75/10 | |||
| Motorspeed | RPM | 2930 | 2940 | 2950 | 297 | |||||||||
| Sarting Method | Y-ΔStarting / Soft starting/ Frequency conversion | |||||||||||||
| Cooling Mode | Air cooling | Air/water cooling | ||||||||||||
| Discharge Temp | °C | Air cooling≤ Ambient temperature+12°C; Water cooling≤38°C | ||||||||||||
| Noise | dB(A) | <68±2 | <70±2 | <75 ±2 | ||||||||||
| Oil content of compressed air | < 2ppm | |||||||||||||
|
Dimension |
Length | mm | 750 | 945 | 945 | 1050 | 1050 | 1120 | 1170 | 1220 | 1500 | 1950 | ||
| Width | mm | 730 | 706 | 706 | 780 | 780 | 800 | 880 | 915 | 1150 | 1450 | |||
| Height | mm | 840 | 1125 | 1125 | 1125 | 1125 | 1200 | 1350 | 1450 | 1580 | 1500 | |||
| Air Outlet Pipe Diameter | inch | G3/4 | G1" | G1" | G1 1/4" | G1 1/4" | G1 1/4" | G1 1/2" | G1 1/2" | DN50 | DN50 | |||
| Cooling Water Pipe Diameter | m3/h | - | - | - | - | - | - | - | - | 5.0 | 6.8 | |||
| Net Weight | KG | 220 | 260 | 290 | 460 | 480 | 550 | 650 | 700 | 1180 | 1350 | |||
Part 2
| Air compressor model | JLS-90F/S | JLS-110F/S | JLS-132F/S | JLS-160F/S | JLS-185F/S | JLS-200F/S | JLS-220F/S | JLS-250F/S | ||||
|
Free Air Delivery (m3/min) (Mpa) |
17.2/0.7 | 21.6/0.7 | 25.6/0.7 | 30.0/0.7 | 34.2/0.7 | 38.6/0.7 | 42.8/0.7 | 45.0/0.7 | ||||
| 16.5/0.8 | 20.6/0.8 | 24.0/0.8 | 29.0/0.8 | 33.0/0.8 | 37.4/0.8 | 40.0/0.8 | 43.1/0.8 | |||||
| 15.0/1.0 | 19.0/1.0 | 22.0/1.0 | 26.2/1.0 | 30.0/1.0 | 34.0/1.0 | 36.5/1.0 | 39.5/1.0 | |||||
| 13.2/1.25 | 17.5/1.25 | 19.0/1.25 | 24.5/1.25 | 28.0/1.25 | 32.0/1.25 | 34.0/1.25 | 36.3/1.25 | |||||
| Motor | Voltage/Prequency | V/Hz | 220V/ 380V/ 415V & 50HZ/ 60HZ | |||||||||
| Power | KW/HP | 90/125 | 110/150 | 132/180 | 160/220 | 185/250 | 200/270 | 220/300 | 250/340 | |||
| Motor speed | RPM | 2970 | 2980 | |||||||||
| Sarting Method | Y-ΔStarting / Soft Starting/ Prequency conversion | |||||||||||
| Cooling Model | Air / water cooling | |||||||||||
| Discharge Temp | °C | Air cooling≤ Ambient temperature+12°C; Water cooling≤38°C | ||||||||||
| Noise | dB(A) | <75±2 | <78±2 | |||||||||
| Oil content of compressed air | < 2ppm | |||||||||||
| Dimension |
Length | mm | 2000 | 2300 | 2300 | 2600 | 2600 | 2600 | 2800 | 2800 | ||
| Width | mm | 1450 | 1700 | 1700 | 1750 | 1750 | 1750 | 2000 | 2000 | |||
| Height | mm | 1500 | 1610 | 1610 | 1910 | 1910 | 1910 | 2000 | 2000 | |||
| Air Outlet Pipe Diameter | inch | DN50 | DN65 | DN65 | DN80 | DN80 | DN100 | DN100 | DN100 | |||
| Cooling Water Pipe Diameter | m3/h | 8.0 | 10.0 | 12.0 | 14.5 | 16.8 | 18.0 | 20.0 | 23.0 | |||
| Net Weight | KG | 1450 | 1950 | 2200 | 2650 | 3800 | 4100 | 4500 | 4550 | |||
ABOUT US:
Fuzhou Xuli Machinery industrial Co.,Ltd. Is a manufacturer of screw air compressor with well-equipped testing facilities and strong technical force.Business is including designing,R&D,production ,marketing ,after service etc.
We build up at 1995 and located at a beauty city call Fuzhou. for now we have 5000 sqm workshop ,most professional CNC processing machine. great management & technological team . The employ is more than 100 people ,including senior engineer ,designer , Technician etc.
We have our own brand ,and also we are able to provide various kinds of screw air compressor base on our clients require.
Our products is well recognized because of it's efficient ,energy-saving,low operation noise and great damping effect.
We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success!
Paired rotary screw air compressor
