Help CenterRFID Animal Tag
Related Products
-
Smallest RFID Glass TagUS$ 0.9 - 0.98MOQ: 100 Pieces -
Big Stock 1.4x8mm Microchip Syringe for Animal!US$ 1.32 - 1.37MOQ: 100 Pieces
-
12mm Needle MicrochipUS$ 1.18 - 1.22MOQ: 1000 Pieces
-
LF Microchip Syringe 2.12X12MMUS$ 1.18 - 1.22MOQ: 100 Pieces
-
Animal Needle Glass TagUS$ 1.18 - 1.22MOQ: 1000 Pieces
SPECIFICATIONS:
- Unsurpassed quality – fully automated manufacturing and direct-bonding technology ensure tag reliability
- Optimum operation – the highest out-of-box performance ratings in the industry, with no line-of-sight requirements
- Practically limitless options – choose from a broad range of standard sizes and integrated chips, or customize to fit any application
TECHNICAL FEATURES:
- ISO 11784 and 11785 compliant
- Multiple IC options, including EM4305, Hitag S, FDX, or HDX
- Bioglass capsules with parylene coating ensure optimal biocompatibility
- Unlimited resistance to water and chemical absorption
- Memory storage up to 2048 bits
- Custom sizes and programming available
TECHNICAL PARAMETER:
Product Code |
KD134-12RW |
|
Electronic |
Operating Frequency |
134.2 kHz |
Chip Type |
EM4305 / HitagS, read/write |
|
Memory |
512 bits / 256bits EEPROM |
|
Reading Distance |
Dependent upon reader, environment and application |
|
Physical |
Dimensions |
Φ2.12 x12 mm |
Tagging Method |
Subcutaneous |
|
Housing Material |
Bio-glass |
|
Chemical and Mechanical |
Water |
IP68, 20°C, 3.3 ft (1 m) x 24 h |
Withstands Exposure To |
Alcohol, ammonium chloride 25%, fuel B, HCL 10%, salt water |
|
Environmental Test Conditions |
20°C, 100 h |
|
Vibration |
IEC 68.2.6 (10 g, 10 to 2000 Hz, 3 axis, 2.5 h) |
|
Shock |
IEC 68.2.29 (40 g, 18ms, 6 axis, 2000 times) |
|
Thermal |
Storage: |
-40° to +90°C, 1000 h |
Operating |
-25° to +85°C |
|
Peak |
120°C, 100 h; 140°C, 10 h |
|
Other |
Standards |
ISO 11784, ISO 11785 |
Options |
Parylene coating (when ordering coating, increase base model number by one), custom programming |
|
Warranty |
2 Years |
|
